7-10 400S 460SJ 3120789
SECTION 7 ELECTRICAL
Ref GROUND CONTROL BOX ASSY COMPONENTS
401 to 404 Not Used
405 1 Engine Harness Assembly Options: (See Items 501-593 for
Breakdown)
4922347 Deutz Engine
4922344 Ford Engine
4922601 Isuzu Engine
406 4922346 1 Valve Harness Assembly 3/C
406A 4460499 14 DIN Connector with Diode
406B 4460320 1 Connector - 2 Position
4460267 2 Pin, Male
406C 4460225 1 Housing, Terminal - 6 Position
4460267 4 Pin, Male
406D 4460445 1 Connector - 3 Position
4460268 3 Socket, Female
406E 4460836 2 Connector, Deutsch - 12 Position
4460837 2 Housing, Terminal Connector
4460465 20 Socket, Female
407 1 Ground Control Box Harness Assembly Options:
4922349 Deutz/Isuzu Engine 5
4922348 Ford Engine 5
3990010 13 Diode 6 Amp (Not Shown)
407A 4460224 1 Connector - 6 Position
4460268 6 Socket, Female
407B 4460225 1 Connector - 6 Position
4460267 6 Pin, Male
407C 4460418 9 Connector - 6 Position
4460419 46 Terminal, Female
407D 4460268 AR Socket, Female
407E 3730099 1 Resistor (Not Shown)
407F 4460420 6 Plug, Relay
4460741 13 Terminal, Relay Plug
408 to 427 Not Used
428 4460526 1 Connector, Strain Relief
429 4460428 3 Connector, Strain Relief
430 4460426 1 Connector, Strain Relief
431 to 452 Not Used
453 4460711 1 Connector, Strain Relief
Ref ENGINE HARNESS ASSEMBLY
4922347 Ref DEUTZ ENGINE 6/G
4922344 Ref FORD ENGINE 5/E
4922601 Ref ISUZU ENGINE 2/B
501 to 534 Not Used
535 4460424 1 Connector - 2 Position
536 4460268 2 Socket, Female
537 to 538 Not Used
FIGURE 7-2. HARNESS COMPONENTS INSTALLATION (WITHOUT ADE SYSTEM)
(CONTINUED)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
