JLG 460SJ ANSI Parts Manual User Manual
Page 130
2-72
SECTION 2 TURNTABLE
2C
1
Voltmeter Options:
2420203
Voltmeter - 110V
7020192
Voltmeter - 220V
2D
1
Pulley Options:
3580134
Pulley 110V (Prior to SN 0300066060)
3580276
Pulley 110V (SN 0300066060 to SN 0300066478)
3580307
Pulley 110V (SN 0300066478 to SN 0300078473)
3580134
Pulley 220V (Prior to SN 0300066060)
3580276
Pulley 220V (SN 0300066060 to SN 0300066478)
3580134
Pulley 220V (SN 0300066478 to SN 0300078473)
7027887
1
Key, Woodruff
3
1
Bracket, Generator Mounting Options:
0902210
Prior to SN 0300064508
0902756
SN 0300064508 to SN 0300078473
4
0200632
1
Arm, Adjusting
5
1
V-Belt Options:
0480118
Generator - 110V (Prior to SN 0300066060)
Use 0480134
Generator - 110V (SN 0300066060 to SN 0300073860) (was
p/n 0480111)
0480134
Generator - 110V (SN 0300073860 to SN 0300078473)
0480118
Generator - 220V
6
0701015
2
Bolt, Metric 10mm-1.5 x 35mm
7
4812000
2
Flatwasher 10mm
8
0100011
AR
Compound, Locking
9
0681612
AR
Bolt 3/8in-16NC x 1-1/2in (Grade 8)
10
4751600
6
Flatwasher 3/8in Regular
11
2860012
1
Key, Woodruff
12
3311605
1
Locknut 3/8in-16NC
13
4564417
1
Spacer, Tube
14
Not Used
15
4460023
1
Connector, Strain Relief
16
0641508
1
Bolt 5/16in-18NC x 1in
17
4751500
2
Flatwasher 5/16in Regular
18
Not Used
19
3520028
1
Plug, Hole
20
0721006
AR
Bolt #10-24NC x 3/4in
21
3311005
AR
Locknut #10-24NC
22
4751000
AR
Flatwasher #10 Regular
23
4360294
1
Breaker, Circuit - 30 Amp (Prior to SN 0300069330)
24
3740080
1
Relay, Bosch
25
4360336
1
Switch, Toggle - SPST (Not Shown - Located at Platform)
26
4740397
1
Washer (Not Shown - Located at Platform)
27
4060802
1
Guard, Switch (Not Shown - Located at Platform)
28
Not Used
29
2820031
1
Heatshrink (Not Shown - Located at Platform)
30
3251102
1
Decal (Not Shown - Located at Platform)
31
0721008
2
Bolt #10-24NC x 1in
32
0641772
1
Bolt 7/16in-14NC x 9in (SN 0300064509 to SN 0300078473)
33
3311705
1
Locknut 7/16in-14NC (SN 0300064509 to SN 0300078473)
FIGURE 2-16. GENERATOR INSTALLATION - FORD MACHINES (PRIOR TO SN 0300078473)
(OPTIONAL) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
