7-8
SECTION 7 ELECTRICAL
FIGURE 7-2. HARNESS COMPONENTS INSTALLATION (WITHOUT ADE SYSTEM)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
Ref
HARNESS COMPONENTS INSTALLATION
4922340
Ref
PLATFORM BOX HARNESS ASSEMBLY
7/F
1
See Note
AR
Switch Harness (Made up of Individual Wires)
(Note: Not Available for Purchase)
2
See Note
AR
Light Display Harness (Made up of Individual Wires)
(Note: Not Available for Purchase)
3
See Note
AR
Fuel Gauge Harness (Made up of Individual Wires)
(Note: Not Available for Purchase)
4 to 38
Not Used
39
7ft/2.13m
Cable, Electrical - 12/4 Options:
1060012
Cable, Electrical (Prior to SN 0300060655)
1060515
Cable, Electrical (SN 0300060655 to SN 0300096000)
40 to 43
Not Used
44
2920129
10
Bulb, Light
45 to 47
Not Used
48
4460265
2
Connector - 9 Position
49
4460418
5
Connector - 6 Position
50
4460419
26
Terminal, Female
51 to 54
Not Used
55
4460720
4
Connector - 15 Position
56
4460721
44
Socket, Female
57 to 59
Not Used
60
4460464
31
Pin, Male (16 Gauge)
61
4460508
4
Pin, Male (12 Gauge)
62
3990001
23
Diode - 3 Amp (Not Shown)
63
Not Used
64
4460225
1
Connector - 6 Position
65
4460267
36
Pin, Male
66
3990010
10
Diode - 6 Amp (Not Shown)
67
Not Used
68
4120035
10
Socket, Light
69
4460326
1
Plug - 3 Position
70
4460634
10
Insert, Terminal (Single Wire)
71
4460635
8
Insert, Terminal (Double Wire)
72 to 89
Not Used
90
4460613
1
Connector - 21 Position
91
4460503
1
Connector - 31 Position
92
4460741
5
Plug - 5 Position
93
4460420
22
Terminal
Ref
PLATFORM BOX ASSEMBLY COMPONENTS
101
4460470
2
Nut, Conduit
102
4460471
2
Washer, Conduit
103
4460428
2
Connector, Strain Relief
