SECTION 5 - GENERAL SPECIFICATIONS AND MAINTENANCE
3121272 – JLG Lift – 5-17
5.9 DIAGNOSTIC TROUBLE CODES (DTC)
The DTC tables following are sorted in groups by the first two digits,
these digits represent the number of flashes the system distress indica-
tor lamp will flash on the platform indicator panel when a fault occurs.
For example: a “2-1 Power-Up” on page 19 would be indicated by 2
flashes, a pause, then 1 flash, a pause, then would keep repeating until
the fault is cleared.
The more detailed three digit code numbers in the DTC column of the
following tables are only indicated on a JLG handheld diagnostic ana-
lyzer.
To troubleshoot multiple DTCs, start with the DTC with the higher first
two digits. If a correction is made during a check, conclude the
check by cycling the machine power off then back on, using the
emergency stop switch.
NOTICE
SHOULD A FAULT OCCUR WHICH CANNOT BE CORRECTED BY THE OPERATOR,
THE PROBLEM MUST BE REFERRED TO A MECHANIC QUALIFIED TO REPAIR
THIS MODEL OF JLG LIFT.
5.10 DTC CHECK TABLE INDEX
DTC TABLE PAGE
0-0 Help Comments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-18
2-1 Power-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-19
2-2 Platform Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-19
2-3 Ground Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-20
2-5 Function Prevented . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-21
3-1 Line Contactor Open Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-22
3-2 Line Contactor Short Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-22
3-3 Ground Output Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-22
4-2 Thermal Limit (SOA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-24
4-4 Battery Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-25
6-6 Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-25
7-7 Electric Motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-26
8-2 LSS - Load Sensing System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-27
8-4 Elevation Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-28
9-9 Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-28
