JLG 26MRT ANSI Parts Manual User Manual
Page 83
3120792
4-15
SECTION 4
PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
FIGURE 4-4. FOLDDOWN HANDRAILS & EXTENSION INSTALLATION (MANUALLY OPERATED
PLATFORM)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
FOLDDOWN HANDRAILS INSTALLATIONS OPTIONS:
Ref.
0252679
Standard
Ref.
5
0257463
CSA
Ref.
4
1
3640738
Handrail - Lower Side
2
2
Not Used
3
Not Used
4
3640740
Handrail - Top Side
2
5
4565191
Tube - Ends
4
6
3640742
Tube - Center (Right Side)
1
7
0641424
Bolt 1/4”-20NC x 3”
A/R
8
4751400
Flatwasher 1/4”
24
9
4761400
Lockwasher 1/4”
18
10
3311401
Nut 1/4”-20NC
18
11
Not Used
12
3520072
Plug, Cap
22
13
Not Used
14
Not Used
15
3430416
Pin, Clevis 1/4” x 2”
16
16
4711400
Flatwasher 1/4”
42
17
3450203
Pin, Cotter 1/16” x 3/4”
16
18
3640743
Handrail - Top Rear Vertical
2
19
Not Used
20
Not Used
21
Not Used
22
1260017
Chain (4 Lengths 7in/17.8cm each)
28in/.7m
23
Not Used
24
0641408
Bolt 1/4”-20 x 1”
4
25
3640761
Handrail - Bottom Rear Vertical
2
26
3421913
Pin, Quick Release
4
27
3535492
Kickplate - Rear
2
28
3640745
Handrail - Rear
1
29
3640753
Tube - Center (Left Side)
1
30
4565261
Handrail - Center Rear Vertical
2
31
Not Used
32
1260136
Chain
2.5ft/.8m
33
3010088
Link
2
34
Use 1001101076
Snap-Latch (Includes Item 33) (was p/n 2940064)
1
35 to 41
Not Used
42
3900184
Screw, Button Head #10-24NC x 5/8”
10
43
3300373
Nut, Joint Connector 1 1/4”
6
44
Not Used
45
3300375
Nut, Joint Connector 2 3/8”
4
46
3340564
Pad
1
47
2820097
Tubing, Mesh
2.5ft/.8m
48
0100011
Loctite #242 (Not Shown)
A/R
