3120792 2-33
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
55 Harness - Mid Engine Lockout Options: (Not Shown) (See
Section 7 for Breakdown) (S/N 32436 to Present) 1
4921960 Prior to S/N 35428
4921961 S/N 35428 to Present
56 3321001 Nut #10-32NF 4
57 4070987 Shim, Nylon (S/N 65027 to Present) 5
58 3910804 Screw #8-32NC x 1/4” (S/N 65027 to Present) 6
59 0641406 Bolt 1/4”-20NC x 3/4” (S/N 70893 to Present) A/R
60 0721004 Bolt #10-24NC x 1/2” (S/N 70893 to Present) 3
61 0722603 Bolt #6-32NC x 3/8” (S/N 70893 to Present) 4
62 Component Options: 1
3520026 Plug (Vanguard Engine)
4360387 Switch, Push Button (Yanmar Engine)
GROUND CONTROL BOX INSTALLATION OPTIONS: Ref.
0256293 Vanguard Engine Ref. 2
0259221 Vanguard Engine - With Hydraulic Drive Generator Ref. 1
0256303 Yanmar Engine Ref. 2
101 Not Used
102 0641410 Bolt 1/4”-20NC x 1 1/4” 2
103 4751400 Flatwasher 1/4” 4
104 4761400 Lockwasher 1/4” 2
105 3311401 Nut 1/4”-20NC 2
106 0362591 Bar, Brace 1
0256536 KEY ATTACH ASSEMBLY Ref. A
201 0641405 Bolt 1/4”-20NC x 5/8” 1
202 4751400 Flatwasher 1/4” 2
203 3311405 Locknut 1/4”-20NC 1
204 1060379 Lanyard 1
205 3760170 Ring 1
OPTIONAL WORKLIGHTS INSTALLATION OPTIONS: Ref.
0256535 Standard Rails Ref. 3
0258925 Fold-Down Rails Ref. 1
301 to 319 Not Used
320 4360448 Breaker, Circuit 10 Amp 1
321 to 322 Not Used
323 4761000 Lockwasher #10 1
324 3311001 Locknut #10-24NC 1
325 3911008 Bolt #10-24NC x 1/2” 1
FIGURE 2-9. GROUND CONTROLS INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
