3120792 4-11
SECTION 4 PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
FIGURE 4-3. WIDE PLATFORM HANDRAILS & EXTENSION INSTALLATION (MANUALLY
OPERATED PLATFORM)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
HANDRAILS INSTALLATION OPTIONS: Ref.
0257225 Standard (Prior to S/N 35882) Ref. 1
0257719 Standard (S/N 35882 to S/N 52320) Ref. 1
0257720 CSA (Prior to S/N 52320) Ref. 2
0258636 Standard & CSA (S/N 52320 to Present) Ref. 2
1 Handrail - Right Side Options: 1
3640727 Standard (Prior to S/N 35882)
3641210 Standard (S/N 35882 to S/N 52320)
3641215 CSA (Prior to S/N 52320)
3641281 Standard & CSA (S/N 52320 to Present)
2 Handrail - Left Side 1
3641173 Standard (Prior to S/N 52320)
3641193 CSA (Prior to S/N 52320)
3641282 Standard & CSA (S/N 52320 to Present)
3 4567057 Tube, Handrail - Rear 1
4 Rail Weldment - End (Left Side) 1
3640730 Prior to S/N 35882
3641194 S/N 35882 to S/N 52320
3641288 S/N 52320 to Present
5 Rail Weldment - End (Right Side) 1
3640731 Prior to S/N 35882
3641195 S/N 35882 to S/N 52320
3641289 S/N 52320 to Present
6 3641160 Rail Weldment - Mid (Rear) 2
7 0641420 Bolt 1/4”-20NC x 2 1/2” 4
8 4751400 Flatwasher 1/4” (Wide) A/R
9 3311405 Locknut 1/4”-20NC 4
10 0641608 Bolt 3/8”-16NC x 1” 2
11 3311605 Locknut 3/8”-16NC 2
12 4751600 Flatwasher 3/8” 4
13 3520072 Plug, Cap 4
14 3539838 Kickplate - Rear 2
15 3640614 Rail Weldment - End (Gate) 1
16 3911034 Screw, Round Head #10-24NC x 2 1/4” 4
17 4751000 Flatwasher #10 4
18 3311005 Locknut #10-24NC 4
19 0961833 Bushing, UHMW 4
20 4420055 Tape, UHMW A/R
21 3900184 Screw, Button Head #10-24NC x 5/8” 16
22 3300373 Nut, Joint Connector 1 1/4” 12
23 3820019 Rivet 6
24 3300375 Nut, Joint Connector 2 3/8” 4
25 0100011 Loctite #242 (Not Shown) A/R
26 3570381 Plate, Placard (S/N 35882 to Present) 1
