SECTION 4 PLATFORM
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
FIGURE 4-2. STANDARD HANDRAILS & EXTENSION INSTALLATION (MANUALLY OPERATED
PLATFORM)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
STANDARD HANDRAILS INSTALLATIONS OPTIONS: Ref.
0251395 Standard (Prior to S/N 38569) Ref. 9
0257696 Standard (S/N 38569 to S/N 52320) Ref. 4
0257985 CSA (Prior to S/N 52320) Ref. 4
0258632 Standard & CSA (S/N 52320 to Present) Ref. 2
0256701 Standard - Safety Attach Points (Prior to S/N 38569) Ref. 1
0257698 Standard - Safety Attach Points (S/N 38569 to S/N
52320) Ref. 4
0257990 Japanese Spec - Safety Attach Points (Prior to S/N
52320) Ref. 3
0257986 CSA - Safety Attach Points (Prior to S/N 52320) Ref. 4
1 Handrail - Right Side Options: 1
3640727 Standard (Prior to S/N 38569)
3641210 Standard & CSA (S/N 38569 to S/N 52320)
3641281 Standard & CSA (S/N 52320 to Present)
3641130 Safety Attach Points (Prior to S/N 38569)
3641213 Safety Attach Points (S/N 38569 to Present)
2 Handrail - Left Side Options: 1
3640728 Standard & CSA (Prior to S/N 52320)
3641300 Standard (S/N 52320 to Present)
3641131 Safety Attach Points
3 4565203 Tube, Handrail - Rear 1
4 1260136 Chain 2ft/.61m
5 3010088 Link 2
6 Use 1001101076 Snap-Latch (Includes Item 5) (was p/n 2940064) 1
7 0641420 Bolt 1/4”-20NC x 2 1/2” A/R
8 Flatwasher Options: A/R
4711400 Flatwasher 1/4” (Narrow) (Prior to S/N 38569)
4751400 Flatwasher 1/4” (Wide) (S/N 38569 to Present)
9 Not Used
10 3311405 Locknut 1/4”-20NC A/R
11 Not Used
12 3520072 Plug, Cap A/R
13 3300373 Nut, Joint Connector 1 1/4” A/R
14 3900184 Screw, Button Head #10-24NC x 5/8” 12
15 3300375 Nut, Joint Connector 2 3/8” 4
16 Tube, Handrail - Rear Vertical Options: 2
3640713 Standard (Prior to S/N 52320)
3641283 Standard & CSA (S/N 52320 to Present)
3641268 CSA (Prior to S/N 52320)
17 3534743 Kickplate - Rear 2
18 0641608 Bolt 3/8”-16NC x 1” 4
19 4751600 Flatwasher 3/8” 4
20 3311605 Locknut 3/8”-16NC 2
21 1702612 Decal - Safety Attach (With Safety Attach Points
Only) 2
