SECTION 2 - TURNTABLE
3121814
E600/E600J/E600JP/M600/M600J/M600JP
59
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
50
7024136
1
Seal Kit - (Includes Items - 1B, 1I, 5, 5A, 11, 12, 15, 26 & 33)
7017088
Ref
HYDRAULIC MOTOR ASSEMBLY
B
101
7024382
7
Bolt
102
7004035
1
Cover, End
103
7024389
1
Seal, Commutator
104
7024389
6
Seal, Rings
105
7024378
1
Commutator and Ring Assembly
107
7024379
1
Manifold
108
7024383
1
Rotor Set
108
7024383
1
Rotor (Note: Not Available - Purchase Rotor Set)
108
7024383
1
Stator (Note: Not Available - Purchase Rotor Set)
108
7024383
1
Vane (Note: Not Available - Purchase Rotor Set)
109
7024380
1
Plate, Wear
110
7024384
1
Link, Drive
112
7024386
1
Shaft, Coupling
113
7024381
1
Bushing, Bronze
114
7004043
2
Thrustwasher
115
7004044
1
Bearing, Thrust
116
7024389
1
Seal, Inner
117
7024389
1
Washer, Back-up
118
7024385
1
Housing
118A
7024389
2
O-Ring
121
7010795
2
Plug
122
7024387
2
O-Ring
123
7024388
2
Spring
124
7017088
1
Valve (Note: Not Available for Purchase)
125
7024389
1
Washer, Back-up
150
7024389
1
Seal Kit (Includes Items 103, 104, 116, 117, 118A & 125)
