SECTION 5 - CYLINDER
3121814
E600/E600J/E600JP/M600/M600J/M600JP
179
FIGURE 5-9. STEER CYLINDER ASSEMBLY (SN 0300165153 to Present)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001140281
Ref
STEER CYLINDER ASSEMBLY
A
Ref
Note: Original Equipment components may have been
replaced with Service Replacement components part. Identify
p/n stamped on cylinder before ordering parts.
1
70004134
1
Barrel
2
70004135
1
Rod
4
70004132
2
Head
5
70004133
2
Spacer
6
70004127
2
Ring, Wear
7
70004127
1
T-Seal
8
70003820
2
O-Ring
9
70002219
2
Retainer
10
70004127
2
Wiper
11
70004127
2
O-Ring
12
70004127
2
Seal
13
70004127
4
Ring, Wear
14
70004127
2
Ring, Backup
15
70004127
2
O-Ring
50
70004127
1
Seal Kit - 1001140281 Cylinder (Includes Items 6-7 & 10-15)
