SECTION 1 - FRAME
3121814
E600/E600J/E600JP/M600/M600J/M600JP
39
FIGURE 1-9. DRIVE VALVE ASSEMBLY (4WD ONLY)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
DRIVE VALVE ASSEMBLY
4641127
Ref
Drive Valve Assembly (Prior to SN 0300102660)
D
1001092586
Ref
Drive Valve Assembly (SN 0300102660 to Present)
A
2
Ref
Manifold Options:
2
See Note
1
4641127 Valve (Note: Not Available for Purchase)
2
1001092586
1
1001092586 Valve
3
Ref
Control Valve Assembly Options:
3
7024011
1
4641127 Valve
3
70001422
1
1001092586 Valve
3
7012773
1
Seal Kit - 4641127 & 1001092586 Valve
3A
7021375
2
Nut
3B
Ref
Coil Options:
3B
7024013
2
4641127 Valve
3B
70002947
2
1001092586 Valve
3C
7012799
1
Lanyard (4641127 Valve Only) (Prior to SN 0300058444)
4
Ref
Control Valve Assembly Options:
4
7024011
1
4641127 Valve
4
70001422
1
1001092586 Valve
4
7012773
1
Seal Kit - 4641127 & 1001092586 Valve
4A
7021375
2
Nut
4B
Ref
Coil Options:
4B
7024013
2
4641127 Valve
4B
70002947
2
1001092586 Valve
4C
7012799
1
Lanyard (4641127 Valve Only) (Prior to SN 0300058444)
5
7012969
1
Cartridge, Check
5
7012540
1
Seal Kit - 7012969 Valve
6
7012969
1
Cartridge, Check
6
7012540
1
Seal Kit - 7012969 Valve
7
7012969
1
Cartridge, Check
7
7012540
1
Seal Kit - 7012969 Valve
8
7012969
1
Cartridge, Check
8
7012540
1
Seal Kit - 7012969 Valve
9
7018942
8
Capscrew #10-24NC x 2in
