SECTION 4 - PLATFORM
3121814
E600/E600J/E600JP/M600/M600J/M600JP
137
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
54
0902588
1
Bracket, Support Platform (Prior to SN 0300194271)
54
1001175997
2
Bracket, Support Platform (SN 0300194271 to Present)
56
Ref
Support, Hand (Left Side) Options:
56
Not Required
0
PVC Box
56
4340678
1
Aluminum Box Only (Prior to SN 0300067706)
57
Ref
Support, Hand (Right Side) Options:
57
Not Required
0
PVC Box
57
4340684
1
Aluminum Box (Prior to SN 0300067706)
58
0641404
8
Bolt 1/4in-20NC x 1/2in
59
0721006
2
Screw, Machine #10-24NC x 3/4in
60
4751000
4
Flatwasher #10 Regular
61
3311005
2
Locknut #10-24NC
62
4740455
4
Washer, Nylon
63
0100009
AR
Adhesive, Silicone
64
1671037
1
Cover (Use p/n 1001110435) (SN 0300067706 to Present)
65
4740397
5
Spacer, Washer (SN 0300194271 to Present)
66
1001155044
5
Nut-spec, 15/32-32 UNS-2B (SN 0300194271 to Present)
Ref
Decal Kit Options (Includes Items 15, 18-22 & 47):
2910866
1
Decal Kit (Prior to SN 0300139882)
3
1001119566
1
Decal Kit (SN 0300139882 to Present)
2
Ref
JIB CONSOLE SWITCH (J AND JP ONLY)
0270018
Ref
JIB CONSOLE SWITCH E600J & M600J
1/B
0270019
Ref
JIB CONSOLE SWITCH E600JP & M600JP
1/B
101
4360328
1
Switch, Toggle
101
3790012
1
O-Ring
101
4922307
1
Harness, Jib Function (See ELECTRICAL SECTION for
Breakdown)
102
Ref
Switch, Toggle Options:
102
Not Required
0
Switch, Toggle E600J & M600J
102
4360328
1
Switch, Toggle E600JP & M600JP
102
3790012
1
O-Ring
0259671
Ref
MOTOR CONTROLS INSTALLATION (M600, M600J & M600JP
ONLY)
1/A
201
4360336
1
Switch, Toggle
201
3790012
1
O-Ring
201
4922222
1
Harness (See ELECTRICAL SECTION for Breakdown)
201
4922223
1
Harness (See ELECTRICAL SECTION for Breakdown)
Ref
SOFT TOUCH COMPONENTS
0270516
Ref
6ft (1.83m) Platform
A
0270405
Ref
8ft (2.44m) Platform
A
4933145
Ref
Electrical Components
2/B
301
4360387
1
Switch, Push Button
302
4460428
1
Connector, Strain Relief
303
1702938
1
Decal - Soft Touch Override
0259338
Ref
WORKLIGHTS INSTALLATION (OPTIONAL)
C
401
Ref
Switch Options:
401A
4360336
1
Switch, Toggle (Prior to SN 0300161820)
401B
4360522
1
Switch, Push Button (SN 0300161820 to Present)
402
1705170
1
Decal, Lights (SN 0300161820 to Present)
