SECTION 2 - PROCEDURES
2-34
– JLG Lift –
3120878
SYSTEMS
BATTERY
TEMPERATURE
PUMP VOLT
PUMP AMP
ELEVATION
Displays measured battery voltage
NOTE: Only accurate when line contactor closed
Displays measured heatsink temperature
Displays calculated pump motor voltage
Displays calculated pump motor current
Displays elevation cutout switch status (OPEN/CLOSED)
Closed with platform fully lowered
DIAGNOSTICS/SYSTEMS
(Continued)
FUNCTION C/O
DECKC/O
DRIVE C/O
POTH C/O
TILT
ARMGUARD
Displays function cutout switch status (OPEN/CLOSED)
Not displayed if FUNTION CUTOUT=NO
Displays function cutout switch status (OPEN/CLOSED)
Not displayed if POWER DECK=NO
Displays function cutout switch status (OPEN/CLOSED)
Not Displayed if DRIVE CUTOUT = NO
Displays pothole cutout switch status (OPEN/CLOSED)
Displays tilt switch status (LEVEL /TILTED)
Not Displayed if TILT SWITCH = NO
Displays armguard cutout switch status (OPEN/CLOSED)
Not displayed if ARMGUARD CUTOUT = NO
Table 2-7. Analyzer Menu Structure
TOP LEVEL MENU
SUB LEVEL MENU
ITEM TO BE VIEWED
OR CHANGED
DESCRIPTION DISPLAY
