Page 31
SECTION 2 - PROCEDURES
3120878
– JLG Lift –
2-19
Steer Adjustment
1.
If necessary, connect a pressure gauge to gauge
port MP, then open the Steer/Tow valve.
2.
Activate drive by pressing the drive switch and acti-
vating the controller to the full forward position.
While holding the controller, activate steer right and
check steer right pressure. If necessary, adjust steer
right pressure to 145 bar (2100 psi)
3.
Activate drive by pressing the drive switch and acti-
vating the controller to the full forward position.
While holding the controller, activate steer left and
check steer left pressure. If necessary, adjust steer
left pressure to 145 bar (2100 psi)..
Figure 2-19. Pressure Setting Adjustments
