SECTION 1 - SPECIFICATIONS
3120765 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 CAPACITIES
Hydraulic Oil Tank
5 gallons (19 liters)
Generator Fuel Tank
4 gallons (15.1 liters)
Drive Axle
Torque Hubs - 19 oz. (0.5 liters)
1.2 COMPONENT DATA
Battery Charger
Input, 110 VAC,60 HZ
Output, 48 VDC (25 Amps)
Batteries (8)
6 Volt, 370 AmpHour (20 hour rate)
Drive System
Drive Motor - 48 VDC, 12.5 H.P. @ 3200 rpm. continuous,
rotation - reversible
Drive Brake- spring-applied, hydraulically released
Tires - IN240/55-17.5 pneumatic or foam filled
Tire Pressure - 90 psi (6.2 Bar)
Hydraulic Pump/Electric Motor Assembly
Motor - 48 VDC, 2.14 H.P. @ 2700 rpm.
Pump - 0.098 in.[3]/rev. (1.6 cm[3]/rev.).
Pump Output - 2.96 gpm (11.2 lpm) @ 3200 psi (222 Bar).
Generator
Alternator Output - 58 volts @ 45 Amps
RPM’s under max. load - 3100
Start Battery - 12 volts
Engine Oil - 10W30 (Refer to Engine Manual)
Dynamo - 12 volt, 15 amp DC
Dynamo Output Fuse - 20 amps DC
Control Fuse - 15 amps DC
1.3 PERFORMANCE DATA
Travel Speed
3.2 mph (5.2 kph)
Gradeability
30% (16.7 degrees)
Turning Radius (Inside)
2ft. 0 in. (0.61 m)
Turning Radius (Curb to Curb)
10 ft. 4 in. (3.15 m)
Tail Swing (Any Position)
0
Upper Boom Speed
Lift Up - 27 seconds
Lift Down - 26 seconds
Lower Boom Speed
Lift Up - 30 seconds
Lift Down - 24 seconds.
Swing Speed - 360 Degrees
90 seconds / rev.
Machine Weight
E45A - 12,600 lb. (5,720 kg)
M45A - 12,800 lb. (5,806 kg)
E45AJ - 14,750 lb. (6690 kg)
M45AJ - 14,750 lb. (6690 kg)
Max. Tire Load
M 45A, E45A - 6100 lbs. (2,767 kg)
M45AJ, E45AJ - 6900 lbs. (3,130 kg)
Updated 2-15-00
