SECTION 1 - SPECIFICATIONS

1-2

– JLG Lift –

3120765

Ground Bearing Pressure

M45A, E45A - 95 psi (6.2 Bar)
M45AJ, E45AJ - 110 psi (7.6 Bar)

Machine Height (stowed)

M45A, E45A - 6 ft. 6.25 in. (1.99 m)

M45AJ, E45AJ - 6ft. 7 in. (2.0 m)

Machine Length (stowed)

M45A, E45A - 18 ft. 8.0 in. (5.69 m)

M45AJ, E45AJ - 21 ft. 2 in. (6.45 m)

Up and Over Platform Height

M45A, E45A - 24 ft. 7 in. (7.49 m)

M45AJ, E45AJ - 25 ft. 3" (7.7 m)

Horizontal Reach @ Maximum Up and Over

M45 A, E45A - 23 ft. 1 in. (7.0 m)

M45AJ, E45AJ - 23 ft. 9 in. (7.24 m)

Machine Width

5 ft. 9 in. (1.75 m)

Wheel Base

6 ft. 7.0 in. (2.00 m)

Working Height

51 ft. 0 in. (15.54 m)

Platform Height

45 ft. 0 in. (13.72 m)

Track Width

5 ft. 0 in. (1.51 m)

Ground Clearance

M45, E45 - 8.5 in. (0.22 m)

M45AJ, E45AJ - 8 in. (0.20 m)

System Voltage

48 volts

Battery Life per Charge

7 hours continuous

Battery Recharge Time

Charger - 17 hours from full discharge

Generator - 6.2 hours

1.4

FUNCTION SPEEDS (M45A/E45A)

Lift Up - 30-24 seconds

Lift Down - 29-23 seconds

Tower Lift Up - 33-27 seconds

Tower Lift Down - 26-22 seconds

Telescope Out - 18-14 seconds

Telescope In - 28-23 seconds

Swing Left 360° - 81-67 seconds*

Swing Right 360° - 81-67 seconds*

Rotate Left 180° - 17-14 seconds

Rotate Right 180° - 18-15 seconds

High Drive - Fwd. & Rev. (200 ft.) - 42-44 seconds**

Drive above Horiz. - Fwd. & Rev. (50 ft.) - 50-53 seconds**

*Swing Left to Swing Right should be within 10% of each other.

**Drive Forward to Drive Reverse should be within 10% of each
other.

1.5

FUNCTION SPEEDS (M45AJ/E45AJ)

Lift Up - 30-24 seconds

Lift Down - 29-23 seconds

Tower Lift Up - 33-27 seconds

Tower Lift Down - 26-22 seconds

Jib Up - 25-26 seconds

Jib Down - 24-25 seconds

Telescope Out - 12-9 seconds

Telescope In - 19-15 seconds
