Page 171
SECTION 4 - PLATFORM
3121270
800S/860SJ
171
FIGURE 4-2. PLATFORM COMPONENTS INSTALLATION (FALL ARRREST PLATFORM)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
PLATFORM ASSEMBLY (FALL ARREST)
3510884
Ref
PLATFORM ASSEMBLY (36 x 72)
E
3510868
Ref
PLATFORM ASSEMBLY (36 x 96)
E
Ref
Note: Replacement Decals Must be Ordered Separately - See
DECALS SECTION.
1
0681814
2
Bolt 1/2in-13NC x 1-3/4in (Grade 8)
2
0681822
AR
Bolt 1/2in-13NC x 2-3/4in (Grade 8)
3
0962270
2
Bearing, Oilite
4
1702773
1
Decal - JLG
5
1705014
1
Decal - Safety
6
2410014
1
Gate Weldment
7
3271805
AR
Locknut 1/2in-13NC (Grade 8)
8
3311605
1
Locknut 3/8in-16NC
9
See Note
1
Platform Weldment (Note: Purchase Platform Assembly)
10
3520072
1
Cap-Plug
11
Ref
Cable, Fall Arrest Options:
11
1060919
1
36 x 72
11
3890040
1
36 x 96
12
3900054
1
Bolt 1/2in-13NC x 1-3/4in
13
4711800
2
Flatwasher 1/2in Thin
14
4751800
AR
Flatwasher 1/2in Regular
15
1706385
1
Decal - Drop Bar
