Page 129
SECTION 2 - TURNTABLE
3121270
800S/860SJ
129
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
304
4922641
1
Switch Harness
1001094475
Ref
HOURMETER INSTALLATION (OPTIONAL)
B
402
0720808
1
Screw #8-32 x 1in
403
2420165
1
Hourmeter
404
3310601
2
Nut #6-32
405
3310805
1
Locknut #8-32
406
3910608
2
Screw #6-32 x 1/2in
407
4240032
4
Strap, Tie
408
4420060
3 in/7cm
Tape, Double-Sided
409
4460234
3
Mount, Tie Strap
410
4750800
1
Flatwasher #8 Regular
411
4760600
2
Lockwasher #6
412
1001094375
1
Bracket, Hourmeter
413
1001094509
1
Harness, Hourmeter
414
4460018
1
Connector, Butt Splice (Not Shown)
1001121340
Ref
TERMINAL BLOCK ASSEMBLY
A
501
70002818
2
Marker Strip #1
502
70002819
4
Marker Strip #2
503
70002820
2
Marker Strip #3
504
70002821
2
Marker Strip #4
505
70002822
4
Marker Strip #5
506
70002823
1
Terminal, End Barrier
507
70002824
2
Terminal, End Block
508
70002825
7
Terminal, Block
509
70002826
2
Terminal, Cross Connector Jumper
510
3641533
1
Rail, Relay
