SECTION 3 - BOOM
160
800S/860SJ
3121270
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001118473
Ref
USA Built Machines (SN 0300141319 through 0300182743
Only)
A
1001118473
Ref
China Built Machines Only (SN B300000100 to Present)
A
301
7012955
1
Valve, CHeck
301
7012967
1
Seal Kit - 7012955 Valve
302
7023984
1
Valve, Flow Regulator
302
7012953
1
Seal Kit - 023984 Valves
303
7012989
1
Valve, Flow Regulator
303
7012953
1
Seal Kit - 7012989 Valve
304
7012965
1
Valve, Flow Regulator
304
7012953
1
Seal Kit - 7012965 Valves
305
7023983
1
Valve, Relief (Level Up)
305
7012967
1
Seal Kit - 7023983 Valve
306
7023911
1
Valve, Relief (Level Down)
306
7012967
1
Seal Kit - 7023911 Valve
307
7017479
1
Valve, Solenoid (Pressure)
307
7012518
1
Seal Kit - 7017479 Valve
308
7012943
1
Coil
309
7023922
1
Valve, Solenoid (Platform Level)
309
7017402
1
Seal Kit - 7023922 Valve
310
7017452
1
Valve, Solenoid (Rotator)
310
7017402
2
Seal Kit - 7017452 Valve
311
7012944
4
Coil
312
7021616
1
Filter (Used on p/n 4641251 Valve Only)
313
7024832
1
Plug (Used on p/n 4641251 Valve Only)
0273695
Ref
LEVEL SENSOR SWITCH INSTALLATION
C
401
0100011
AR
Compound, Locking
402
0100035
AR
Compound, Locking
403
0641406
4
Bolt 1/4in-20NC x 3/4in
404
0641604
6
Bolt 3/8in-16NC x 1/2in
405
3930606
4
Capscrew #6-32NC x 3/8in
406
1671044
2
Cover, Sensor
407
3200449
2
Mount, Sensor
408
3440410
2
Rollpin
409
Ref
Switch, Tilt Sensor Options:
409
4360544
2
Sensor-Analog (USA Built Machines) (Use p/n 1001135114) (SN
0300140000 through 0300161729 Only)
409
4360544
2
Sensor-Analog (China Built Machines) (Use p/n 1001135114)
(SN B300000100 through B300000639 Only)
409
1001133329
2
Sensor-Digital (USA Built Machines) (SN 0300161730 through
0300182743 Only)
409
1001133329
2
Sensor-Digital (China Built Machines Only) (SN B300000640 to
Present)
410
4711600
6
Flatwasher 3/8in Thin
