SECTION 2 - TURNTABLE
102
800S/860SJ
3121270
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
116
3311005
2
Locknut #10-24NC
117
0641608
6
Bolt 3/8in-16NC x 1in
118
1321384
4
Hold Down
119
0641606
4
Bolt 3/8in-16NC x 3/4in
120
2600209
1
Hinge
121
3960464
65
in/1.67m
Seal
122
3960462
61
in/1.55m
Seal
123
See Note
1
Insulation, Heat (GM Engine Only) (Note: Use Item 101 - Cover
complete inside of hood with insulation. Fasten with Item 125
Tape.)
124
See Note
1
Insulation, Heat (GM Engine Only) (Note: Use Item 101 - Cover
complete inside of hood with insulation. Fasten with Item 125
Tape.)
125
1001117140
AR
Tape, Aluminized Polyester (GM Engine Only)
126
0100011
AR
Compound, Locking (GM Engine Only)
1671228
Ref
HOOD ASSEMBLY (TANK SIDE)
A
Ref
Note: Replacement Decals Must be Ordered Separately - See
DECALS SECTION.
201
1671231
1
Hood
202
1671232
1
Frame, Tubular
203
2940088
2
Latch
204
0721008
4
Screw, Machine #10-24NC x 1in
205
4751000
4
Flatwasher #10 Regular
206
3311005
4
Locknut #10-24NC
207
2600233
1
Hinge
208
1321384
4
Hold Down
209
0641606
9
Bolt 3/8in-16NC x 3/4in
210
4711600
9
Flatwasher 3/8in Thin
211
3960464
83
in/2.11m
Seal
212
3960438
55 in/1.4m Seal
213
3960462
53
in/1.35m
Seal
0272081
Ref
NOISE REDUCTION INSTALLATION (DEUTZ/CATERPILLAR
ENGINE MACHINES) (OPTIONAL)
4
301
2820078
1
Foam, Acoustical (Turntable Side)
