SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
11 Hardware Options: 1
7000796 Screw, Bleeder (Prior to S/N 33906)
7018609
Plug, Pipe (S/N 33906 to S/N 51532)
Not Required S/N 57512 to Present
12 Pin, Dowel Options: 2
7007987 0920084 Brake (Prior to S/N 33476)
7007987
0920110 Brake (S/N 33476 to S/N 51532)
Not Available 0920119 Brake (S/N 57512 to Present)
13 Kit Seal, Oil 1
14 Ring, Retaining Options: 1
7011716
0920084 Brake (Prior to S/N 33476)
7011716 0920110 Brake (S/N 33476 to S/N 51532)
Kit 0920119 Brake (S/N 57512 to Present)
15
Kit
Bearing 1
16 Ring, Retaining 1
7007977 0920084 Brake (Prior to S/N 33476)
7007977 0920110 Brake (S/N 33476 to S/N 51532)
Kit
0920119 Brake (S/N 57512 to Present)
17
Kit
Ring, Back-Up 1
18 Kit Ring, Back-Up 1
19 Kit O-Ring 1
20
Kit
O-Ring 1
21 Piston Options: 1
7007923 0920084 Brake (Prior to S/N 33476)
7018603
0920110 Brake (S/N 33476 to S/N 51532)
Not Available
0920119 Brake (S/N 57512 to Present)
22 7007933 Gasket 2
23 7007990 O-Ring 2
24
7007924
Plug, Pipe 1
— — — — — — — — — — —
Repair Kits:
0920084 Brake (Prior to S/N 33476)
2900766
Seal Kit (Includes Items 8,13,17,18,19,20,22 &
23) 1
2900768 Seal Kit (Includes Items 8,13,15,22 & 23) 1
2900767 Lining Kit Options: (Includes Items 5,6,7,8,22 &
23) 1
0920110 Brake (S/N 33476 to S/N 51532)
2900766 Seal Kit (Includes Items 8,13,17,18,19,20,22 &
23) 1
2900768 Seal Kit (Includes Items 8,13,15,22 & 23) 1
7018608
Lining Kit Options: (Includes Items 5,6,7,8,22 &
23) 1
0920117 (S/N 51532 to S/N 57512)
7018612 Complete Repair Kit (Includes Items 5,6,7,8,13,
17, 18,19,20,22 & 23) 1
0920119 (S/N 57512 to Present)
7018612 Complete Repair Kit (Includes Items 5,6,7,8,13,
17, 18,19,20,22 & 23) 1
FIGURE 1-12. BRAKE ASSEMBLY - MICO (2WD JANUARY 1992 TO PRESENT AND 4WD JULY 1991
TO PRESENT) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
