JLG 80HX_HX+6 Parts Manual - Manual (Page 301)

3120800 6-9
S
E
C
T
I
O
N
6
H
Y
D
R
A
U
L
I
C
S
SECTION 6 HYDRAULICS
FIGURE 6-4. HYDRAULIC DIAGRAM - BRAKE WITH PRESSURE REDUCING VALVE (USED WITH
AUSCO DRIVE BRAKES)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
2791553
HYDRAULIC DIAGRAM - BRAKE WITH PRESSURE
REDUCING VALVE (USED WITH AUSCO DRIVE
BRAKES) Ref. B
1 4640522 Valve, Pressure Reducing 1
3311401
Nut 1/4"-20NC 2
4761400
Lockwasher 1/4" 2
4751400 Flatwasher 1/4" 2
4300036 Stud (Welded on Part) 2
2
2220250
Fitting, Reducer 1
3
2220752
Fitting, Tee 2
4 2220428 Fitting, Quick Disconnect 1
5 2220429 Cap, Dust 1
6
2220414
Fitting 1
7 2220585 Fitting, 90° 2
8 2751010 Hose 1
9 2751397 Hose 1
10
2220605
Fitting, Tee 1
11 2751018 Hose 1
12 4640197 Valve, Check 1
13
2220584
Fitting 1
14
2220618
Fitting, Reducer 1
15 2220679 Fitting, Tee 1
