JLG 80HX_HX+6 Parts Manual User Manual
Page 196
2-126
3120800
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
43
Switch, Emergency Stop Options:
1
4360289
Prior to S/N 44643
4360475
S/N 44643 to Present
Cap Options:
1
7012611
Cap, Mushroom Head (Used on Switch p/n
4360289)
7012612
Boot (Used on Switch p/n 4360289)
1
7020175
Cap, Red (Used on Switch p/n 4360475)
7020176
Contact Block (Used on Switch p/n 4360475)
44
4360274
Switch, Pushbutton
1
45
4360284
Switch, Key (Prior to S/N 44643)
1
7010698
Key, Replacement
1
4360468
Switch, Key (S/N 44643 to Present)
1
2860030
Key, Replacement
1
46
Block, Contact SPST N.O. Options:
A/R
4360267
Prior to S/N 49405
Not Required
S/N 49405 to Present
47
Block, Contact SPST N.O. Options:
A/R
4360281
Prior to S/N 49405
Not Required
S/N 49405 to Present
48
3790012
O-Ring
5
49
4360200
Switch, Toggle
1
50
4360202
Switch, Toggle
4
51
2920029
Light, Bulb
1
52
4420037
Strip, Rubber
33 in./7.6cm
53
3300177
Nut, Tinnerman
2
54
0750806
Screw #8 x 3/4"
2
55 to 56
Not Used
57
3911016
Screw, Machine #10-24NC x 1"
1
58
4460244
Connector, Strain Relief
1
59
4360212
Breaker, Circuit - 3 Amp (When Equipped)
1
60
1704260
Decal, EMS (Not Shown)
1
GROUND CONTROL INSTALLATION
Ref.
0252489
Prior To March 1995
Ref.
2
0257163
March 1995 To Present
Ref.
2
101
0861085
Ground Control Box Assembly (Includes Items 1 - 59)
1
102
1780234
Door
1
103
2940042
Latch
1
104
3380309
Panel, Gauge
1
105
0100011
Loctite #242 (Not Shown)
A/R
106
2420091
Voltmeter
1
107
4751400
Flatwasher 1/4"
10
108
2420009
Hourmeter
1
109
0641406
Bolt 1/4"-20NC x 3/4"
6
110
4761400
Lockwasher 1/4"
16
111
3311401
Nut 1/4"-20NC
13
112
Not Used
FIGURE 2-32. GROUND CONTROL COMPONENTS INSTALLATION (MACHINE BUILT S/N 25609 TO
PRESENT) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
