SECTION 2 TURNTABLE
0238777
HEATERS AND CONTROLS INSTALLATION
Ref.
D
301
1600043
Control, Thermoswitch
1
302
2580018
Heater, Immersion
2
303
0231756
Junction Box Assembly (See Items 401-403 for Break-
down)
2
304
3311401
Nut 1/4"-20NC
4
305
4761400
Lockwasher
4
306
4300031
Stud (Welded on Part)
4
307
3251836
Nameplate - Engine/Battery Manifold Heater (Left Box)
1
308
3251272
Nameplate - Hydraulic Oil Tank Heater (Right Box)
1
309
3251243
Nameplate - 120V-60Hz
2
0231756
JUNCTION BOX ASSEMBLY
Ref.
C
401
4460137
Receptacle, Female (1 Per Assembly)
1
4460082
Receptacle, Male (1 Per Assembly)
1
402
4460007
Strip, Terminal (1 Per Assembly)
1
403
4460049
Connector, Strain Relief (3 Per Assembly)
3
0255869
FUEL FILL EXTENSION KIT
Ref.
A
Note: For use on fuel tanks built prior to June 1995.
Tanks built June 1995 to present are already
equipped with extension.
501
4845158
Fill Tube Extension Weldment
1
502
3960465
Seal
1
FUEL CAP ASSEMBLY
Ref.
0236285
Standard Non-Locking (Prior to June 1995)
Ref.
5/E
0255823
Standard Non-Locking (June 1995 to S/N 30382)
Ref.
2/B
0257365
Standard Non-Locking (S/N 30382 to Present)
Ref.
1
0257366
Locking Protectoseal (Red)
Ref.
2
0258626
Locking Protectoseal (Blue)
Ref.
1
601
Cap, Fill Options:
1
1120314
Standard Non-Locking Cap
1120367
Locking Protectoseal (Red)
1120512
Locking Protectoseal (Blue)
FIGURE 2-28. TANKS INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
