JLG 400CRT Parts Manual User Manual
Page 75
3121805
3-11
SECTION 3 SCISSOR ARMS
S
E
C
T
I
O
N
3
S
C
I
S
S
O
R
A
R
M
S
.
FIGURE 3-3. ARM GUARDS INSTALLATION
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0259594
ARM GUARDS INSTALLATION
Ref.
E
1
0641612
Bolt 3/8”-16NC x 1 1/2”
24
2
0641824
Bolt 1/2”-13NC x 3”
6
3
0641826
Bolt 1/2”-13NC x 3 1/4”
4
4
3311805
Locknut #8-32NC
10
5
4061013
Shield (Side)
A/R
6
4061014
Shield (Front)
A/R
7
4340715
Support (Front Left)
A/R
8
4340716
Support (Front Right)
A/R
9
4340717
Support (Rear Left)
A/R
10
4340718
Support (Rear Right)
A/R
11
4711800
Flatwasher 1/2” Narrow
10
12
4751600
Flatwasher 3/8”
30
13
0182008
Angle
A/R
14
0561410
Block, Spacer
2
15
0561411
Block, Spacer
2
16
0641405
Bolt 1/4”-20NC x 5/8”
4
17
0641407
Bolt 1/4”-20NC x 7/8”
32
18
Not Used
19
2080056
Fastener, Insert 3/8”-16NC
24
20
3311405
Locknut 1/4”-20NC
40
21
3572410
Plate (Front)
A/R
22
3572411
Plate (Rear)
A/R
23
4061015
Shield (Rear)
A/R
24
Not Used
25
4280311
Strip, Rubber (Side)
2
26
4280312
Strip, Rubber (Front)
1
27
4280313
Strip, Rubber (Rear)
1
28
4711400
Flatwasher 1/4” Narrow
32
29
4751400
Flatwasher 1/4”
8
30
Not Used
31
0561415
Block, Spacer
4
32
0641409
Bolt 1/4”-20NC x 1 1/8”
4
33
0641607
Bolt 3/8”-16NC x 7/8”
6
34
2080058
Fastener, Insert
6
35
3572449
Plate, Backing
A/R
36
3572450
Plate, Backing
A/R
37
3572452
Plate, Backing
A/R
38
0100011
Loctite #242 (Not Shown)
A/R
— — — — — — — — — —
2902126
Support Kit - Includes Items 7 thru 10
1
2902127
Arm Guard Kit - Includes Items 5,6,13,21,22,23,35,36 & 37
1
