Page 53
3121805
2-3
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
.
FIGURE 2-1. RIGHT SIDE COMPARTMENT INSTALLATIONS
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0259559
HYDRAULIC COMPONENTS INSTALLATION
Ref.
K
Note: Replacement Decals must be Purchased
Separately - See Section 8.
Ref.
1
0100011
Loctite #242 (Not Shown)
A/R
2
0641407
Bolt 1/4”-20NC x 7/8”
A/R
3
0641506
Bolt 5/16”-18NC x 3/4”
5
4 to 5
Not Used
6
0651404
Bolt 1/4”-48NF x 1/2”
2
7
Not Used
8
1380136
Clip, Gripper
2
9
1670926
Cover, Hydraulic Tray
1
10
2080052
Fastener 1/4”-20NC
8
11
Pressure Filter Assembly Options:
1
2120146
With Electrical Clog Indicator
1
2120209
With Manual Clog Indicator
1
Note: All machines equipped with 2120146 filter from
the factory. However, if the filter was replaced after
leaving the factory, it may have been replaced with a
2120209 filter. Check clog indicator to determine
which filter is on the machine.
7023206
O-Ring
1
11A
Element, Filter Options:
1
2120150
Element, Filter - p/n 2120146
1
2120210
Element, Filter - p/n 2120209
1
11B
Indicator, Clog Options:
1
7016312
Electrical Indicator - p/n 2120146
1
7020020
Manual Indicator - p/n 2120209
1
12 to 13
Not Used
14
2940126
Latch
1
15
Not Used
16
3820019
Rivet
2
17
4400426
Hydraulic Tank Assembly
1
L
17A
7014802
Gauge, Sight
1
17B
7014811
Cap, Breather
1
17C
7014816
Screen
1
7020256
Neck
17D
7020253
Strainer
1
17E
7014813
Plug, Magnetic
1
7014812
Magnet
1
18
Not Used
19
4641157
Main Control Valve Assembly (See Figure 2-2 for Break-
down)
1
20
4641147
Flow Divider Assembly (See Figure 2-3 for Breakdown)
1
21
4711400
Flatwasher 1/4” Narrow
A/R
22
4711500
Flatwasher 5/16” Narrow
11
23
3311405
Locknut 1/4”-20NC
A/R
24
3572229
Plate, Splash
1
25
3310805
Locknut #8-32NC
4
