SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
26
3311505
Locknut 5/16”-18NC
1
27
3900289
Screw, Phillips Head #8-32NC
4
28
3900208
Screw 3/8”-16NC x 1”
1
29
Not Used
30
4750800
Flatwasher #8
4
31
4060808
Flex-Trim
6ft/1.8m
32
3572362
Plate, Cover
1
33
4761500
Lockwasher 5/16”
1
34
0641524
Bolt 5/16”-18NC x 3”
4
35
4568114
Tube, Spacer
4
36
0641405
Bolt 1/4”-20NC x 5/8”
4
37
1780317
Door
1
38
2600147
Hinge, Door
1
39
0641410
Bolt 1/4”-20NC x 1 1/4”
8
ELECTRICAL COMPONENTS INSTALLATIONS
Ref.
0259839
Diesel Machines
Ref.
D
0259840
Diesel Machines with Leveling Jacks
Ref.
A
101
0140001
Horn
1
102
Ground Control Box Assembly Options: (See Figure 2-4 for
Breakdown)
1
0270069
Diesel Machines (Production)
0270424
Diesel Machines (Post Production)
0270424
Diesel Machines with Leveling Jacks
103
0641404
Bolt 1/4”-20NC x 1/2”
A/R
104
0641406
Bolt 1/4”-20NC x 3/4”
4
105
0641506
Bolt 5/16”-18NC x 3/4”
1
106
0902590
Bracket, Ground Control Box
2
107
3311405
Locknut 1/4”-20NC
A/R
108
3311505
Locknut 5/16”-18NC
1
109
4751500
Flatwasher 5/16”
2
110
4761400
Lockwasher 1/4”
4
111
Engine & Valve Harness Options: (Not Shown - See
Section 7 for Breakdown)
1
4922343
Diesel Machines
4922441
Diesel Machines with Leveling Jacks
112
4711400
Flatwasher 1/4” (Narrow)
1
FIGURE 2-1. RIGHT SIDE COMPARTMENT INSTALLATIONS (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
