3121805 5-13
SECTION 5 CYLINDERS
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-5. LIFT CYLINDER COMPONENTS ASSEMBLY - 400CRT
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0259561 LIFT CYLINDER SUB-ASSEMBLY Ref. J
1 0080228 Adapter 2
2 0100011 Loctite #242 (Not Shown) A/R
3 to 16 Not Used
17 Manual Descent Cable Assembly Options: 1
0259859 Prior to S/N 80106
(See Items 201-209 for Breakdown)
1060846 S/N 80106 to Present (See Items 17A & 17B)
17A 7020218 T-Handle 1
17B 7019602 Bellows 1
18 to 21 Not Used
22 0641506 Bolt 5/16”-18NC x 3/4” 4
23 to 27 Not Used
28 0902421 Bracket 2
29 to 41 Not Used
42 3321402 Nut, Jam 1/4”-28NF 4
43 to 54 Not Used
55 Cartridge Valve Options: (Manual Descent) 1
Cartridge Valve (Lower Lift Cylinder)
4641001 Prior to S/N 80106
4641172 S/N 80106 to Present
Cartridge Valve (Upper Lift Cylinder)
4641001 Prior to S/N 80106
4641168 S/N 80106 to Present
Cartridge Only Options: 1
7017445 4641001/4641172 Valve
7017467 4641168 Valve
Use 7012998 Seal Kit - 4641001, 4641172 & 4641168
Valve (was p/n 7012967) 1
Coil Options: 1
7017444 4641001 Valve
7012943 4641172 Valve
7012944 4641168 Valve
56 4641118 Valve, Thermal Relief 2
7012998 Seal Kit - 4641118 Valve (1 Per Valve) 2
57 4711400 Flatwasher 1/4” Narrow 4
58 to 69 Not Used
70 3450405 Pin, Cotter 2
71 to 74 Not Used
75 1320122 Clamp 1
76 Not Used
77 1670995 Cover, Cable (Not Shown) 1
78 4280295 Strip, Protector (Not Shown) A/R
