3121118 E600/E600J E600JP M600/M600J M600JP 2-3
SECTION 2 TURNTABLE
FIGURE 2-1. VALVE AND HORN INSTALLATIONS
ITEM # PART NUMBER QTY. DESCRIPTION REV.
Ref VALVE AND HORN INSTALLATIONS
0270096 Ref E600 & M600 G
0270097 Ref E600J & M600J G
0270098 Ref E600JP & M600JP G
1 0100011 AR Locking, Compound
2 0140028 1 Horn
3 0641507 1 Bolt 5/16in-18NC x 7/8in
4 0641606 6 Bolt 3/8in-16NC x 3/4in
5 Not Used
6 0741005 2 Bolt #10-24NC x 5/8in
7 1320070 1 Clamp
8 1380136 2 Clip
9 Not Used
10 3311005 2 Locknut #10-24NC
11 3311505 1 Locknut 5/16in-18NC
12 Not Used
13 3900283 7 Screw, Button Head
14 Not Used
15 Use 1001092566 1 Main Control Valve Assembly (was p/n 4641123 & p/n 4641235)
(See MAIN CONTROL VALVE ASSEMBLY for Breakdown)
16 to 17 Not Used
18 4711500 8 Flatwasher 5/16in Thin
19 4711600 13 Flatwasher 3/8in Thin
20 Not Used
21 4751000 4 Flatwasher #10 Regular
22 4846183 1 Tray Weldment
