7-6 E600/E600J E600JP M600/M600J M600JP 3121118
SECTION 7 ELECTRICAL
FIGURE 7-2. HARNESS COMPONENTS INSTALLATION (WITH MAC CHARGER)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
Ref HARNESS COMPONENTS INSTALLATION
Ref PLATFORM BOX ELECTRICAL DIAGRAM OPTIONS:
4933112 Ref ANSI Spec - E600J/M600J/E600JP/M600JP G/G
Ref ANSI Spec - E600/M600
4933112 Ref Prior to SN 0300172558 4/F
1001154137 Ref SN 0300172558 to Present A
4933183 Ref UL Spec - E600J/E600JP 5/E
Ref UL Spec - E600
4933183 Ref Prior to SN 0300172558 5/E
1001154136 Ref SN 0300172558 to Present A
1 1 Harness, Indicator Lamp Options:
4922074 Prior to SN 0300141894 5/H
1001109860 SN 0300141894 to Present B
1A 4460265 1 Connector - 9 Position
4460227 8 Pin, Male
1B 4120035 AR Socket, Lamp
1C 4460634 AR Socket (Single Wire)
4460635 AR Socket (Two Wire)
2 1 Harness, Function Switch Options:
4922303 1 E600J/M600J/E600JP/M600JP 5/D
4922303 1 E600/M600 (Prior to SN 0300172558) 5/D
4922060 1 E600/M600 (SN 0300172558 to Present) 2/C
2A 4460434 1 Connector - 15 Position
4460226 12 Pin, Male
2B 4460464 2 Pin, Male
2C 4460418 4 Connector, Female
4460419 12 Terminal
2D 4460225 1 Connector - 6 Position (Used with Harness p/n
4922303 Only)
4460227 5 Socket, Female
2E 4460343 1 Connector - 12 Position (Used with Harness p/n
4922303 Only)
4460227 5 Socket, Female
3 4922071 1 Harness, Can Bus 2/B
3A 4460321 1 Connector - 4 Position
4460227 2 Pin, Male
4460267 1 Pin, Male
3B 4460464 3 Pin, Male
4 1 Harness, Box Horn Options:
4922118 ANSI Spec 2/B
4922555 UL Spec 1/A
4A 4460464 1 Pin, Male
5 1 Harness, Miscellaneous Options:
4922157 ANSI Spec 4/D
4922556 UL Spec B
5A 4460464 AR Pin, Male
