E600/E600J E600JP M600/M600J M600JP
SECTION 7 ELECTRICAL
Ref
GROUND CONTROL BOX DIAGRAM
4933110
Ref
Prior to SN 0300099756
2/F
4933387
Ref
SN 0300099756 to Present
1/A
501
Ref
Ground Control Harness Assembly
4922350
Prior to SN 0300099756
6/F
4923627
SN 0300099756 to Present
2/E
501A
4460424
1
Connector, 2 Position
4460268
2
Socket, Female
501B
4460464
4
Pin, Deutsch
501C
4460225
1
Connector - 6 Position
4460227
5
Pin, Male
501D
4460320
AR
Connector, Female - 2 Position
4460227
AR
Pin, Male
501E
4460265
1
Connector - 9 Position
4460227
3
Pin, Male
501F
4460434
1
Connector - 15 Position
4460226
13
Socket, Female
Ref
DRIVE CABLES INSTALLATIONS
0259741
Ref
ANSI Spec (Prior to SN 0300112387)
E
0274284
Ref
ANSI Spec (SN 0300112387 to Present)
D
0270382
Ref
UL Spec (Prior to SN 0300112387)
C
0274285
Ref
UL Spec (SN 0300112387 to Present)
C
601 to 602
Not Used
603
1001116521
1
Drive Orientation Harness
603A
4460320
1
Plug, Male - 2 Position
4460227
2
Pin, Male
603B
4460424
1
Connector, Female - 2 Position
4460226
2
Socket, Female
604
Use 4360517
Proximity Switch Harness (Includes Switch)
604A
4460320
1
Plug, Male - 2 Position
4460227
2
Pin, Male
605 to 607
Not Used
608
1
Electrical Cable Options: (B Motor A1 to Contactor MB2)
1060782
ANSI Spec
1060851
UL Spec
609
1
Electrical Cable Options: (A Motor A1 to Contactor MA1)
1060783
ANSI Spec
1060852
UL Spec
610
1
Electrical Cable Options: (A Motor A2 to Contactor MA2)
1060784
ANSI Spec
1060853
UL Spec
611
1
Electrical Cable Options: (B Motor S1 to Contactor SB1)
1060785
ANSI Spec
1060854
UL Spec
FIGURE 7-2. HARNESS COMPONENTS INSTALLATION (WITH MAC CHARGER)
(CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
