SECTION 4 - MACHINE OPERATION
3121212 – JLG Lift – 4-11
Transport Vehicle Tie Down
(See Figure 4-6.)
When placing the 15AMI machine onto a transport vehicle for
transport to another work-site, always tie machine securely to
the transport vehicle using the tie down pockets provided on the
machine. There are four tie down pockets, one on each corner
of the machine. There are also two cross strap saddles at the
center on each side of the base frame. Use corner tie down
pockets and cross strap saddles as needed. Tie down method
shown is for illustrative purposes only.
Figure 4-6. 15AMI Tie Down Pockets.
1. Corner Tie-Down Pockets 2. Cross Strap Saddles
1 2
1
