SECTION 3 - MACHINE CONTROLS & INDICATORS
3121212 – JLG Lift – 3-3
4. HYDRAULIC RESERVOIR / CIRCUIT BREAKER / FUSE
(located inside ground control station housing)
The hydraulic reservoir is housed inside the ground con-
trol station, the hydraulic oil level can be checked through
an access hole in the side of the cover. Maintain an oil
level to the "Fill to Line" indicator on the side of the reser-
voir.
NOTE: Check hydraulic oil only when platform is completely low-
ered and after cycling platform up/down a few times.
A 20 amp reset type circuit breaker is located on the cover
of the electrical box on AMI-AC Models.
On AMI-DC Models, a 5 Amp fuse is located inside the
ground control station.
Figure 3-2. Manual Descent Control Valve Location -
Machines Built Since S/N- 0900019526.
1. Manual Descent Control Valve
2. Cut-Out at Rear of Base Frame
1
2
