JLG 40HA Parts Manual User Manual
Page 92
2-36
3120805
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
0252106
DEUTZ ENGINE ASSEMBLY - STANDARD BANG-
BANG OR PROPORTIONAL CONTROLS AND WITH
NOISE REDUCTION PACKAGE OCTOBER 1991 TO
PRESENT (VARIABLE PARTS)
Ref.
G
51
2420110
Sender, Oil Pressure
1
52
Pump Assembly Options:
1
3600172
Pump-Barnes (October 1991 to January 1993)
(See Figure 2-15 for Breakdown)
3600199
Pump-Barnes (January 1993 to Present) (See Fig-
ure 2-16 for Breakdown)
53
4640751
Valve, Oil Drain
1
54
2750532
Hose
1 ft./.3m
55
1320022
Clamp
1
56
4711400
Flatwasher 1/4” (August 1995 to Present)
1
57
0700605
Bolt Metric 6mm x 10mm (August 1995 to Present)
2
58
2180104
Fitting, Nipple (August 1995 to Present)
1
59
2200261
Fitting, Coupling (August 1995 to Present)
1
DEUTZ ENGINE INSTALLATION (STANDARD
PARTS)
Ref.
151
1320041
Clamp
1
152
2720271
Line, Fuel Return
10 ft./3m
153
2720058
Line, Fuel Supply
10 ft./3m
154
4300032
Stud (Welded on Part)
A/R
155
4761400
Lockwasher 1/4"
A/R
156
3311401
Nut 1/4"-20NC
A/R
157
1320022
Clamp
4
158
2220805
Fitting, 90°
1
159
2220063
Fitting, 90° Swivel
1
160
4420001
Tape, Sealant
A/R
161
0080039
Adaptor, Elbow
1
162
Not Used
163
1060172
Cable, Battery
1
164
0400075
Battery
1
165
Not Used
166
3960389
Seal, Rubber Grip
51 in./1.3m
167
3980007
Seat, Battery
1
168
Not Used
169
4761600
Lockwasher 3/8"
4
170
0340002
Band, Air Cleaner
2
171
1060273
Cable, Battery (Battery to Auxiliary Relay)
1
172
1060099
Cable, Battery (Starter to Auxiliary Power Relay)
1
173
Not Used
174
Not Used
175
1320019
Clamp, Exhaust
A/R
176
4300034
Stud (Welded on Parts)
2
177
3311601
Nut 3/8"-16NC
2
178
0641856
Bolt 1/2"-13NC x 7"
4
179
4761800
Lockwasher 1/2"
4
FIGURE 2-13. DEUTZ ENGINE INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
