7-2 3120805
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
FIGURE 7-1.ELECTRICAL DIAGRAM LIST
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
7—1 ELECTRICAL DIAGRAM LIST Ref.
Note: Diagrams with asterisks (*) are shown in the
following pages. Diagrams not shown re available
from the JLG Service Department. Ref.
Alarm Electrical Diagrams Options Ref.
Machines Built Prior to January 1993: Ref.
4931947/
1281985
Travel/Back-up/Swing Descent Electrical Dia-
gram Ref. G/G
0610091 Card, Circuit 1
3740049 Relay 1
4931946 Motion Electrical Diagram Ref. —
3990010 Diode - 6 Amp 2
3740049 Relay, Bosch - SPDT 1
0140016 Alarm, Horn 1
4931954 Tilt Electrical Diagram (5º) Ref. 5
0140016 Alarm, Horn 1
3740049 Relay, Bosch - SPDT 1
4360089 Flasher - 12V 1
Machines Built January 1993 to Present: Ref.
4932638/
1282091
Travel Electrical Diagram Ref. 2/D
0610104 Card, Circuit 1
4932639/
1282091
Motion Electrical Diagram Ref. 2/D
3740049 Relay 1
3990010 Diode - 6 Amp 2
1060341 Cable, Electrical - 16/2 8 ft./2.5m
0253077 Tilt Electrical Diagram Ref. 5
0140026 Alarm 1
1540002 Capacitor 1
4932490 Australian Spec Modification Wiring Diagram Ref. B
0254240/
1281701
Cold Weather Electrical Diagram (Deutz) Ref. B/D
4932362/
1281526
Collector Ring Electrical Diagram (4WS) Ref. A/C
1060042 Cable, Electrical - 16/5 15 ft.
4460049 Connector, Strain Relief (At Ground Control Box) 1
0960239 Bushing 1
3300047 Nut, Conduit 1
Drive Cutout Wiring Diagrams Ref.
4932321 Eight Meter Drive Cutout (Austrian, Dutch and Ger-
man Spec) Ref. A
3740057 Relay 1
4120012 Socket 1
