JLG 40HA Parts Manual - Manual (Page 169)

3120805 5-1
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
SECTION 5 CYLINDER
TABLE OF CONTENTS
FIGURE DESCRIPTION PAGE
5-1 AXLE LOCKOUT CYLINDER ASSEMBLIES -(Use With Optional Oscillating Axle). . . . . . . . . . 5-2
5-2 PLATFORM LEVEL CYLINDER ASSEMBLY (Machines Built Prior to October 1992) . . . . . . . . 5-4
5-3 PLATFORM LEVEL CYLINDER ASSEMBLY (Machines Built October 1992 to Present). . . . . . 5-6
5-4 LEVEL (UPRIGHT) CYLINDER ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
5-5 LIFT CYLINDER ASSEMBLY - Main Boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
5-6 LIFT CYLINDER ASSEMBLY - Tower Boom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
5-7 STEER CYLINDER ASSEMBLIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20
5-8 TELESCOPE CYLINDER ASSEMBLY - Main Boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-22
5-9 CYLINDER BELLOWS INSTALLATION (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-24
5-10 MANUAL DESCENT INSTALLATION (Australian, French and Italian Spec) . . . . . . . . . . . . . . . 5-26
