Page 12
1-4
3120805
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
55
Valve, Relief Options:
1
Not Required
Prior to October 1994
4640812
October 1994 to Present
AXLE INSTALLATION - 4WD MACHINES WITH
OPTIONAL OSCILLATING AXLE (VARIABLE
PARTS)
Ref.
0251329
BUILT PRIOR TO OCTOBER 1994
Ref.
D
0255070
BUILT OCTOBER 1994 TO PRESENT
Ref.
—
61
Front Axle Weldment Options:
1
4843447
Prior to October 1994
4844849
October 1994 to Present
0961029
Bushing, Bronze
4
62
Lockout Cylinder Assembly Options (See Section 5
for Breakdown):
2
1682406
Cylinder - Prior to June 1992
1682757
Cylinder - June 1992 to Present
63
Pin Options:
1
4842621
Prior to October 1994
3422401
October 1994 to Present
64
O-Ring Options:
2
Not Required
Prior to October 1994
3780183
October 1994 to Present
65
Valve, Relief Options:
1
Not Required
Prior to October 1994
4640812
October 1994 to Present
0236449
STEERING AND SPINDLES INSTALLATION - 2WD
MACHINES
Ref.
O
101
1681562
Steer Cylinder Assembly (See Section 5 for Break-
down)
1
102
3840863
Tie-Rod
1
103
Not Used
104
Kingpin Options:
2
3421243
Prior to February 1994
3422261
February 1994 to Present
105
0440183
Bearing, Thrust
2
106
3960098
Seal, Hub
2
107
3300012
Nut, Wheel
18
108
0630137
Stud, Wheel
18
109
2780091
Hub Assembly
2
110
1120032
Cap, Hub
2
111
0721003
Bolt #10-24NC x 3/8"
6
112
4761000
Lockwasher #10
6
113
4740016
Washer, Hardened
2
114
3323403
Nut 1 1/2"- 6NF
2
115
3451012
Pin, Cotter 5/16" x 3"
2
FIGURE 1-1. FRAME, STEERING AND AXLE INSTALLATIONS - 2WD AND 4WD (WITH 2 WHEEL
STEER) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
