Page 80
2-20
SECTION 2 TURNTABLE
FIGURE 2-5. CATERPILLAR DIESEL ENGINE INSTALLATION
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
Ref
CATERPILLAR DIESEL ENGINE INSTALLATION OPTIONS:
Ref
With Rexroth Pumps & ABS Hoods
1001120526
Ref
With Skypower & Without Cold Weather Plus Package
C
1001120527
Ref
With Skypower & With Cold Weather Plus Package
C
Ref
With Rexroth Pumps & Steel Hoods
1001117499
Ref
With Skypower & Without Cold Weather Plus Package
D
1001120528
Ref
With Skypower & With Cold Weather Plus Package
C
1
0100011
AR
Compound, Locking
2
0100079
AR
Sealant, Pipe
3
0641606
4
Bolt 3/8in-16NC x 3/4in
4
0641506
AR
Bolt 5/16in-18NC x 3/4in
5
0641509
18
Bolt 5/16in-18NC x 1-1/8in
6
0641511
1
Bolt 5/16in-18NC x 1-3/8in
7
0641605
3
Bolt 3/8in-16NC x 5/8in
8
0641608
3
Bolt 3/8in-16NC x 1in
9
0641610
1
Bolt 3/8in-16NC x 1-1/4in
10
0641611
2
Bolt 3/8in-16NC x 1-3/8in
11
0641612
2
Bolt 3/8in-16NC x 1-1/2in
12
0641808
1
Bolt 1/2in-13NC x 1in
13
0642010
1
Bolt 5/8in-11NC x 1-1/4in
14
0700808
1
Bolt M8 x 16mm
0761210
1
Bolt M12 x 20mm
15
1320022
5
Clamp
16
1320187
1
Clamp, Twin
17
1320190
1
Cover, Clamp
18
1671121
1
Cover, Generator
19
2180348
1
Fitting, Barbed
20
2200222
1
Plug, Pipe (Used in Bottom of Fuel Tank) (Not Shown)
21
2220313
1
Fitting, Elbow Barbed
22
2221176
1
Fitting, Elbow
23
2750532
55in/1.4m
Hose
24
2820170
1
Insulation, Sound Absorbing
25
3311505
AR
Locknut 5/16in-18NC
26
3311605
4
Locknut 3/8in-16NC
27
1
Panel, Rubber Options:
3380472
Machines with ABS Hoods
1001111132
Machines with Steel Hoods
28
1
Panel, Rubber Options:
3380473
Machines with ABS Hoods
1001128899
Machines with Steel Hoods
29
3422446
1
Pin
30
3573644
1
Plate, Tray Clamp
31
1
Plate, Top Clamp Options:
3573645
Machines with ABS Hoods
1001112878
Machines with Steel Hoods
32
1
Plate, Bottom Clamp Options:
3573646
Machines with ABS Hoods
1001112879
Machines with Steel Hoods
