6-20
SECTION 6 HYDRAULIC
FIGURE 6-7. HYDRAULIC DIAGRAM LIST
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
Ref
Note: Diagrams With Asterisk (*) Are Shown In The Preceding
Pages. Information on diagrams not shown is available from
JLG Service/Parts Departments.
Ref
Hydraulic Diagram - Boom (1200SJP) Options:
1283308
Ref
Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps (Prior to SN 0300074357)
1283308
Ref
Hydraulic Diagram for Deutz BF4M2011 & TD2011 Engine
Machines with Rexroth Pumps (Prior to SN 0300074357)
1283374
Ref
Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps (SN 0300074357 to SN 0300100131)
1283374
Ref
Hydraulic Diagram for Deutz BF4M2011 & TD2011 Engine
Machines with Rexroth Pumps (SN 0300074357 to
SN 0300100131)
1283457*
Ref
Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps (SN 0300100131 to Present)
1283457*
Ref
Hydraulic Diagram for Deutz BF4M2011 & TD2011Engine
Machines with Rexroth Pumps (SN 0300100131 to Present)
1001152971*
Ref
Hydraulic Diagram for Deutz TCD2.9L4 Engine Machines
with Rexroth Pumps
2792561
Ref
Prior to SN 0300074357
2792625
Ref
SN 0300074357 to SN 0300100131
2792625*
Ref
SN 0300100131 to SN 0300119707
1001098025*
Ref
SN 0300119707 to Present
1001118859*
Ref
Hydraulic Diagram (Sauer Pumps)
1001098025*
Ref
SN 0300119707 to Present
Ref
Hydraulic Diagram - Boom (1350SJP) Options:
1283308
Ref
Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps (Prior to SN 0300074357)
1283308
Ref
Hydraulic Diagram for Deutz BF4M2011 & TD2011 Engine
Machines with Rexroth Pumps (Prior to SN 0300074357)
1283374
Ref
Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps (SN 0300074357 to SN 0300100131)
1283374
Ref
Hydraulic Diagram for Deutz BF4M2011 & TD2011 Engine
Machines with Rexroth Pumps (SN 0300074357 to
SN 0300100131)
1283457*
Ref
Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps (SN 0300100131 to Present)
1283457*
Ref
Hydraulic Diagram for Deutz BF4M2011 & TD2011Engine
Machines with Rexroth Pumps (SN 0300100131 to Present)
1001152971*
Ref
Hydraulic Diagram for Deutz TCD2.9L4 Engine Machines
with Rexroth Pumps
2792557
Ref
Prior to SN 0300074357
2792626
Ref
SN 0300074357 to SN 0300100131
2792626*
Ref
SN 0300100131 to SN 0300119707
1001098026*
Ref
SN 0300119707 to Present
1001118859*
Ref
Hydraulic Diagram (Sauer Pumps)
1001098026*
Ref
SN 0300119707 to Present
