Page 242
3-24
SECTION 3 BOOM
34
4
Sensor, Angle Indicator Options: (Note: Control System must be
recalibrated when Sensor is replaced)
Use 1001147479
Prior to SN 0300141600 (was p/n 4360534 & p/n 4360545)
Use 1001133329
SN 0300141600 to SN 0300157203 (was p/n 4360545)
1001133329
SN 0300157203 to Present
35
4460914
2
Terminal, Base
36
4711400
10
Flatwasher 1/4in Thin
37
4711600
2
Flatwasher 3/8in Thin
38
4891400
4
Flatwasher 1/4in Hardened
39
0641406
4
Bolt 1/4in-20NC x 3/4in
40
4460428
2
Connector, Strain Relief
41
4846484
1
Mount, Switch
42
1
Pad, Rubber Options:
3340861
Prior to SN 0300132905
3340941
SN 0300132905 to Present
43
1705366
1
Decal - Boom Length (500LB Cap)
44
Use 3574616
1
Plate, Boom Length (was p/n 3573503)
45
4240032
2
Tie-Strap (Prior to SN 0300088626)
46
Not Used
6
Screw 5/16in-18NC x 1in
47
1705367
1
Decal - Boom Length (1000LB Cap)
48
4460968
3
Connector, Strain Relief (Not Shown)
49
1320136
2
Clamp, Cable (Not Shown)
50
4341158
2
Plate, Mounting Sensor (SN 0300088626 to Present)
51
8310070
6
Pushnut 3/8in (SN 0300088626 to Present)
52
6
Screw Options:
0791604
Screw 3/8in-16NC x 1/2in (Prior to SN 0300088626)
0791605
Screw 3/8in-16NC x 5/8in (SN 0300088626 to Present)
53
0100081
AR
Adhesive (SN 0300132905 to Present)
FIGURE 3-5. BOOM SENSORS AND SWITCHES INSTALLATION (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
