SECTION 1 - SPECIFICATIONS
3121127 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 OPERATING SPECIFICATIONS
1.2 CAPACITIES
1.3 TIRES
1.4 BATTERY CHARGER
1.5 DIMENSIONAL DATA
Table 1-1. Operating Specifications
Maximum Work Load (Capacity)
Unrestricted:
500 lb. (230 kg)
Travel Speed 3.2 mph (5.2 kph)
Maximum Travel Grade (Gradeablility 30%
Maximum Travel Grade (Side Slope) 5°
Maximum Height: (stowed)
E450A/M450A
E450AJ/M450AJ
6 ft. 6.25 in. (1.9 m)
6 ft. 7 in. (2.0 m)
Maximum Horizontal Platform Reach
E450A
E450AJ
23 ft. 1in.(7.0 m)
23 ft. 9 in. (7.24 m)
Turning Radius (Curb to Curb) 15 ft. 3 in. (4.65 m)
Turning Radius (inside) 2 ft. (0.61 m)
Maximum Tire Load:
M450A, E450A
M450AJ, E450AJ
6100 lbs. (2,767 kg)
6900 lbs. (3,130 kg)
Ground Bearing Pressure
M450A, E450A
M450AJ, E450AJ
64 psi (4.5 kg/cm 2 )
75 psi (5.2 kg/cm 2 )
System Voltage 48 volts
Battery Life per Charge 7 hours continuous
Battery Recharge Time
Charger
Generator
17 hours from full discharge
6.2 hours
Gross Machine Weight ( Platform Empty )
E450A/M450A
E450AJ/M450AJ 13,100 lb. (5942 kg)
15,100 lb. (6804 kg)
Table 1-2. Capacities
Generator Fuel Tank 4 Gallons (15.1 L)
Hydraulic Oil Tank 5 Gallons (19 L) w/ 10% air space
Hydraulic System (Including Tank) 9 Gallons (34.1 L)
Torque Hub, Drive
*
17 ounces (0.50 L)
*Torque hubs should be one half full of lubricant.
Table 1-3. Tire Specifications
Size IN240/55-17.5 IN240/55-17.5 26x7x20
Load Range E E - -
Ply Rating 10 10 - -
Tire Pressure 90 psi (6.2 Bar) Foam-Filled Solid, Non-
Marking
Table 1-5. Dimensional Data
Machine Length (stowed)
M450A, E450A
M450AJ, E450AJ
18 ft. 8.0 in. (5.69 m)
21 ft. 2 in. (6.45 m)
Up and Over Platform Height
M450A, E450A
M450AJ, E450AJ
24 ft. 7 in. (7.49 m)
25 ft. 3 in. (7.7 m)
Horizontal Reach @ Maximum
Up and Over
M450 A, E450A
M450AJ, E450AJ
23 ft. 1 in. (7.0 m)
23 ft. 9 in. (7.24 m)
Machine Width 5 ft. 9 in. (1.75 m)
Wheel Base 6 ft. 7.0 in. (2.00 m)
Working Height 51 ft. 0 in. (15.54 m)
Platform Height 45 ft. 0 in. (13.72 m)
Track Width 5 ft. 0 in. (1.51 m)
Tail Swing (Any Position) 0
Ground Clearance
M450, E450
M450AJ, E450AJ
8.5 in. (0.22 m)
8 in. (0.20 m)
Table 1-4. Generator
Input 110 VAC,60 HZ
Output 48 VDC (25 Amps)
Quantity of Batteries 8
Battery Spec 6 Volt, 370 Amp Hour
(20 hour rate)
