ELECTRICAL
31200725 G5-18A, 2505H, 25.5 10-35
Figure 10-10 Cab Harness (Continued)
SW05
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1
2
WHT 052-1 HORN 16 AWG GXL
3 RED 061-2-2 HORN SW 16 AWG GXL
4
5
6
7
BLK 000-8-16 GND 16 AWG GXL
7 BLK 000-8-17 GND 16 AWG GXL
8 WHT 070-1-6 LIGHTING 16 AWG GXL
8 WHT 070-1-7 LIGHTING 16 AWG GXL
X15
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1 YEL 062-12-2 IGN 16 AWG GXL
2 WHT 076-8 LSI C/O 16 AWG GXL
3 BLK 000-7-2 GND 16 AWG GXL
4
5
SHIELD LSI S 18 AWG SHLD
6 RED LSI 1 16 AWG GXL
7 BLK LSI 2 16 AWG GXL
8 BLU LSI PWR 16 AWG GXL
9 WHT 085-1 LSI LP 16 AWG GXL
10 SHIELD CABLE 3 CAN S 18 AWG SHLD
11 RED CABLE 3 CAN HI 18 AWG CABLE
12 BLK CABLE 3 CAN LO 18 AWG CABLE
X17
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1 WHT 065-1-2 STR SEL 16 AWG GXL
2 YEL 062-2-2 IGN 16 AWG GXL
3 WHT 070-1-2 LIGHTING 16 AWG GXL
4 YEL 062-4-4 IGN 16 AWG GXL
X16
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1 BLK 000-7-3 GND 16 AWG GXL
2 YEL 062-13-1 IGN 16 AWG GXL
3 RED 061-9 B+ 16 AWG GXL
4 WHT 074-9 R WPR 16 AWG GXL
5 WHT 074-8 R WPR 14 AWG GXL
6 BLK 000-6-4 GND 14 AWG GXL
7
8
X22
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1 WHT 051-6 FR WK LP 16 AWG GXL
2 BLK 000-8-3 GND 16 AWG GXL
3 WHT 051-7 RR WK LP 16 AWG GXL
4 BLK 000-8-2 GND 16 AWG GXL
5 WHT 072-1 BEACON LP 16 AWG GXL
6 BLK 000-8-1 GND 16 AWG GXL
MS290-1
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
A BLK CABLE 2 CAN LO 18 AWG CABLE
B RED CABLE 2 CAN HI 18 AWG CABLE
C SHIELD CABLE 2 CAN S 18 AWG SHLD
MS290-2
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
A BLK CABLE 1 CAN LO 18 AWG CABLE
B RED CABLE 1 CAN HI 18 AWG CABLE
C SHIELD CABLE 1 CAN S 18 AWG SHLD
MS290-3
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
A BLK CABLE 3 CAN LO 18 AWG CABLE
B RED CABLE 3 CAN HI 18 AWG CABLE
C SHIELD CABLE 3 CAN S 18 AWG SHLD
X211
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1 YEL 062-1 IGN RLY 16 AWG GXL
2
3
WHT 048-1 START 16 AWG GXL
4 RED 061-5 KEY 16 AWG GXL
5
6
SW19
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1
2
YEL 062-2-5 IGN 16 AWG GXL
3 WHT 076-7 JS C/O 16 AWG GXL
4 WHT 065-1 LOCK OUT 16 AWG GXL
5 YEL 062-2-3 IGN 16 AWG GXL
5 YEL 062-2-4 IGN 16 AWG GXL
6 WHT 065-4-2 2W STR 16 AWG GXL
7 BLK 000-8-19 GND 16 AWG GXL
7 BLK 000-8-20 GND 16 AWG GXL
8 WHT 070-1-10 LIGHTING 16 AWG GXL
8 WHT 070-1-11 LIGHTING 16 AWG GXL
MS18
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1 RED 061-2-1 R PWR 16 AWG GXL
2 BLK 000-8-4 GND 16 AWG GXL
SW20
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
3
6
WHT 065-3 4W STR 16 AWG GXL
9 BLK 000-8-20 GND 16 AWG GXL
9 BLK 000-8-21 GND 16 AWG GXL
10 WHT 070-1-11 LIGHTING 16 AWG GXL
10 WHT 070-1-12 LIGHTING 16 AWG GXL
11 WHT 065-2 CRB STR 16 AWG GXL
12
13
WHT 065-1 LOCK OUT 16 AWG GXL
13 WHT 065-1-1 LOCK OUT 16 AWG GXL
14
15
WHT 065-4 2W STR 16 AWG GXL
16 WHT 065-1-1 LOCK OUT 16 AWG GXL
16 WHT 065-1-2 STR SEL 16 AWG GXL
SW26
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1
2
YEL 051-2 FR WK LP 16 AWG GXL
3 WHT 051-6 FR WK LP 16 AWG GXL
4
5
6
7
BLK 000-8-22 GND 16 AWG GXL
7 BLK 000-8-23 GND 16 AWG GXL
8 WHT 070-1-13 LIGHTING 16 AWG GXL
8 WHT 070-1-14 LIGHTING 16 AWG GXL
SW21
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1
2
YEL 051-3 BM WK LP 16 AWG GXL
3 WHT 051-5 BOOM LP 16 AWG GXL
4
5
6
7
BLK 000-8-21 GND 16 AWG GXL
7 BLK 000-8-22 GND 16 AWG GXL
8 WHT 070-1-12 LIGHTING 16 AWG GXL
8 WHT 070-1-13 LIGHTING 16 AWG GXL
SW23
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1
2
YEL 051-4 RR WK LP 16 AWG GXL
3 WHT 051-7 RR WK LP 16 AWG GXL
4
5
6
7
BLK 000-8-23 GND 16 AWG GXL
7 BLK 000-8-24 GND 16 AWG GXL
8 WHT 070-1-14 LIGHTING 16 AWG GXL
8 WHT 070-1-15 LIGHTING 16 AWG GXL
SW30
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1 WHT 074-6 FR WASH 16 AWG GXL
2 YEL 062-15 IGN 16 AWG GXL
2 YEL 062-15-1 IGN 16 AWG GXL
3
4
WHT 074-2-1 WPR L 14 AWG GXL
5 WHT 074-4 WPR P 14 AWG GXL
6 WHT 074-5 WPR P 14 AWG GXL
7 BLK 000-8-25 GND 16 AWG GXL
7 BLK 000-8-26 GND 16 AWG GXL
8 WHT 070-1-16 LIGHTING 16 AWG GXL
8 WHT 070-1-17 LIGHTING 16 AWG GXL
SW29
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1 WHT 074-4 WPR P 14 AWG GXL
2 YEL 062-17 IGN 14 AWG GXL
3 WHT 074-1 WPR 14 AWG GXL
4 WHT 074-2 WPR L 14 AWG GXL
4 WHT 074-2-1 WPR L 14 AWG GXL
5 WHT 074-1 WPR 14 AWG GXL
6 WHT 074-3 WPR H 14 AWG GXL
7 BLK 000-8-24 GND 16 AWG GXL
7 BLK 000-8-25 GND 16 AWG GXL
8 WHT 070-1-15 LIGHTING 16 AWG GXL
8 WHT 070-1-16 LIGHTING 16 AWG GXL
SW32-AC
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
A WHT 073-6 AC 16 AWG GXL
B WHT 073-5 AC 16 AWG GXL
C BLK 000-6-8 GND 16 AWG GXL
SW31
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1 WHT 074-9 R WPR 16 AWG GXL
2 YEL 062-16 IGN 14 AWG GXL
2 YEL 062-16-1 IGN 14 AWG GXL
3 WHT 074-8 R WPR 14 AWG GXL
4
5
YEL 062-16-1 IGN 14 AWG GXL
6 WHT 074-7 R WPR 16 AWG GXL
7 BLK 000-8-26 GND 16 AWG GXL
8 WHT 070-1-17 LIGHTING 16 AWG GXL
SW32-F
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
B YEL 062-18 IGN 12 AWG GXL
C WHT 073-4 AC 16 AWG GXL
H WHT 073-1 FAN H 14 AWG GXL
L WHT 073-3 FAN L 14 AWG GXL
M WHT 073-2 FAN M 14 AWG GXL
X215
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1 YEL 062-10 IGN 8 AWG GXL
X216
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1 RED 061-6 BATTERY 10 AWG GXL
X217
CONN
POS
WIRE
COLOR
WIRE
LABEL
GAUGE JACKET
1 BLK 000-5 GND 6 AWG EPDM
PY9020
