SECTION 2 - PREPARATION AND INSPECTION
2-8
– JLG Lift –
3120742
18.
Ground Controls 35/n35 electric - Switches opera-
ble; no visible damage; emergency stop switch
functions properly; placards secure and legible.
19.
Battery Charger - No damage; properly
secured.
20.
Valve - No loose or missing parts; evidence of
leakage, unsupported wires or hoses; dam-
aged or broken wires.
21.
Boom/Upright - No visible damage; All pins properly
secured. Upright in vertical position. If Upright does
not rest on stop with machine in the stowed position,
this indicates upright is out of plumb. (See Section
2-20 in service manual 3120743, for Boom Synchro-
nizing procedure.)
22.
Steer Wheel/Tire Assembly, Right Front - Prop-
erly secured; no loose or missing wheel bolts;
no visible damage.
23.
Counterweight - No loose or missing hardware;
properly secured.
24.
Steer Cylinder - Properly secured; no visible
damage or signs of leakage; evidence of
proper lubrication.
25.
Oscillating axle 35/n35/40/n40/45 electric -
No loose or missing hardware; no visible dam-
age; evidence of proper lubrication.
26.
Hydraulic Oil Filter Housing 30 electric -
Secure; no visible signs of damage or leakage.
27.
Tie Rod Ends and Steering Spindles - No loose
or missing parts; no visible damage. Tie rod
end stubs locked.
28.
Drive Wheel/Tire Assembly, Left Rear - Properly
secured; no loose or missing wheel bolts; no visible
damage.
29.
Ground Controls 40/n40/45 electric -
Switches operable; no visible damage; emer-
gency stop switch functions properly; placards
secure and legible.
30. Manual Descent Valve 40/n40/45 electric -
No visible damage; no evidence of leakage.
31.
Cowling and Latches 40/n40/45 electric - All
cowling, doors and latches in working condi-
tion; properly secured; no loose or missing
parts.
32.
Battery Compartment - Batteries have proper
electrolyte level; cables tight; no visible dam-
age or corrosion.
33. Control Valve 40/n40/45 electric - No loose or
missing parts; evidence of leakage; unsup-
ported wires or hoses; damaged or broken
wires.
34.
Swing Motor and Worm Gear - No loose or
missing hardware; no visible damage; evi-
dence of proper lubrication.
35.
Drive Wheel/Tire Assembly, Left Rear - Properly
secured; no loose or missing wheel bolts; no
visible damage.
36.
Drive Motor, Brake and Hub, Left Rear - No visi-
ble damage; no evidence of leakage.
37.
Frame - No visible damage; no loose or miss-
ing hardware (top and underside).
38.
Cowling and Latches - All cowling, doors and
latches in working condition; properly secured;
no loose or missing parts.
39.
Platform Pivot Pins - Properly secured; evi-
dence of proper lubrication.
40. Platform Gate - Latch and Hinges in working
condition; properly secured; no loose or miss-
ing parts.
Figure 2-3. Daily Walk-Around Inspection. (Sheet 3 of 3)
