SECTION 1 - SPECIFICATIONS
1-2
– JLG Sizzor –
3120696
NOTE: Wheel lugs should be torqued to 80 ft lb (112 Nm) at
50 hour intervals.
When maintenance becomes necessary or a fas-
tener has loosened, refer to the Torque Chart, Figure
1-1, to determine proper torque value.
Hydraulic Filter - Inline
Return - Bypass Type
25 Micron Nominal
1.3
PERFORMANCE DATA
Travel Speed
2 Wheel Drive - 3.5 mph (5.6 kmh)
4 Wheel Drive - 2.8 mph (4.5 kmh)
Gradeability
2 Wheel Drive - 25% (14°)
4 Wheel Drive - 45% (24°)
Turning Radius (Outside)
2 Wheel Steer - 13 ft 2 in (4.0 meters)
4 Wheel Steer - 6 ft 6 in (2.0 meters)
Lift Speed - 400RTS
Up - 42 - 50 seconds
Down - 60 - 70 seconds
Lift Speed - 500RTS
Up - 65 - 80 seconds
Down - 70 - 80 seconds
Platform Capacity - Fixed Platform
400RTS - 2,000 lb. (907 kg)
500RTS - 2,500 lb. (1134 kg)
Platform Capacity - Traversing Platform
Extension (If Equipped)
400RTS (With Deck Extended)
Main Deck - 1,500 lb (680 kg)
Extension - 500 lb (227 kg)
500RTS (With Deck Extended)
Main Deck - 2,000 lb (907 kg)
Extension - 500 lb (227 kg)
With Deck Retracted
400RTS - 1,500 lb (680 kg)
500RTS - 2,000 lb (907 kg)
Platform Capacity - Wide Deck, Dual
Extensions (500RTS Only)
500RTS - 1500 lb (680 kg)
Machine Weight
400RTS - Approx. 14,985 lb (6,797kg)
500RTS - Approx. 15,300 lb (6,940 kg)
Machine Height (Platform Lowered)
400RTS - 116.625 in (2.9 m)
500RTS - 126.3125 in (3.15 m)
Machine Length
15 ft 5 in (4.72 meters)
Machine Width
Standard Tires - 7 ft 6 in (2.3 meters)
Foam Filled Tires - 7 ft 7 in (2.3 meters)
1.4
LUBRICATION
NOTE: Hydraulic oils must have anti-wear qualities at least
to API Service Classification GL-3, and sufficien-
themical stability for mobile hydraulic system service.
JLG Industries recommends Mobil 424 hydraulic oil,
which has an SAE viscosity of 10W-20 and viscosity
index of 152.
NOTE: Aside from JLG recommendations, it is not advisable
to mix oils of different brands or types, as they may
not contain the same required additives or be of
comparable viscosities. If use of hydraulic oil other
Table 1-1. Hydraulic Oil
HYDRAULIC SYSTEM OPERAT-
ING
TEMPERATURE RANGE
SAE VISCOSITY GRADE
0 to +23 degrees F
(-18 to -5 degrees C)
10W
0 to +210 degrees F
(-18 to +100 degrees C)
10W-20,10W-30
+50 to +210 degrees F
(+10 to +100 degrees C)
20W-20
