SECTION 2 - TURNTABLE
3121299
660SJ/600S
53
FIGURE 2-6. SWING DRIVE, TURNTABLE BEARING AND LOCK INSTALLATIONS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001150390
Ref
SWING DRIVE INSTALLATION
D
1
0100019
AR
Compound, Locking
2
Ref
Bolt Options:
2
Ref
USA Built Machines
2
0642018
1
Bolt 5/8in - 11NC x 2-1/4in (SN 0300171769 through
0300179726)
2
0682018
1
Bolt 5/8in - 11NC x 2-1/4in (Grade 8) (SN 0300179727 to
Present)
2
0682018
1
China Built Machines (Bolt 5/8in - 11NC x 2-1/4in (Grade 8)
3
0682216
4
Bolt 3/4in - 10NC x 2in Grade 8
4
3312002
1
Nut, Jam 5/8in - 11NC
5
3900293
1
Capscrew 1in x 1-1/4in
6
4740057
4
Flatwasher, Hardened
7
1001101060
1
Swing Hub Assembly (See SWING MOTOR/HUB ASSEMBLY for
Breakdown)
8
4071009
1
Shim
1001150391
Ref
TURNTABLE BEARING AND REMOTE LUBE INSTALLATION
C
101
0100019
AR
Compound, Locking
102
0440207
1
Bearing, Turntable
103
0682018
36
Bolt 5/8in - 11NC x 2-1/4in Grade 8
104
3020029
AR
Lubricant
105
4892000
36
Flatwasher 5/8in Hardened
106
0100011
AR
Compound, Locking
107
1001149927
1
Hose (Includes Grease Fitting and Adapter Fittings)
1001151203
Ref
TURNTABLE LOCK INSTALLATION
B
201
3421627
1
Pin
202
3421565
1
Pin, Snap
203
3760170
2
Ring, Quick Release
204
1260017
9 in/23cm
Chain
