SECTION 2 - TURNTABLE
124 660SJ/600S 3121299
FIGURE 2-20. HOODS (STEEL) AND LIFTING PLATE INSTALLATIONS (DEUTZ D2011 AND GM
ENGINES)
ITEM PART NUMBER QTY DESCRIPTION REV
1001150241 Ref HOODS INSTALLATIONS B
1 0100011 AR Compound, Locking
2 0100081 AR Adhesive
3 0641406 4 Bolt 1/4in-20NC x 3/4in
4 0641506 5 Bolt 5/16in-18NC x 1in
5 0641608 14 Bolt 3/8in-16NC x 7/8in
6 0641611 2 Bolt 3/8in-16NC x 1-3/8in
7 0681618 2 Bolt 3/8in-16NC x 2-1/4in (Grade 8)
8 Ref Fastener Options:
8 0641810 8 Bolt 1/2in-13NC x 1-1/4in
8 0811812 8 Screw 1/2in-13NC x 1-1/2in
9 0940049 2 Stopper, Hood
10 2080040 6 Fastener, Huck
11 2940045 1 Latch, Paddle
12 Ref Nut Options:
12 3300364 3 Nut, Tinnerman
12 3311505 3 Locknut 5/16in-18NC
13 3311405 4 Locknut 1/4in-20NC
14 3311501 4 Nut 5/16in-18NC
15 3311601 1 Nut 3/8in-16NC
16 3311605 AR Locknut 3/8in-16NC
17 3520030 1 Plug, Hole
18 3900210 8 Screw, Button Head 5/16in-18 x 3/4in
19 3900316 10 Screw, Button Head 3/8in-16NC x 1in
20 3960389 50 in/1.3m Seal
21 4160194 4 Spring, Gas
22 4751400 4 Flatwasher 1/4in Regular
23 4751500 AR Flatwasher 5/16in Regular
24 4751600 AR Flatwasher 3/8in Regular
25 1001110166 12 ft/30cm Seal
26 1001113047 77 in/2m Seal
27 1001117234 1 Bracket, Hood
28 1001117249 1 Plate, Seal
29 1001117307 1 Decal - Emergency Stop
30 1001117523 1 Bracket, Striker Plate
31 1001117525 1 Bracket, Striker Plate
32 1001117598 1 Door
33 Ref Bracket, Hood Mounting Options:
33 1001118264 2 Bracket, Hood Mounting (SN 0300171769 through 0300179027)
33 1001157867 2 Bracket, Hood Mounting (SN 0300179028 to Present)
34 1001118550 1 Bracket, Hood Support
35 1001118735 1 Plate, Filler
36 1001119283 1 Hood, Fixed Engine Side
Ref Note: Replacement Decals must be Purchased Separately -
See DECALS SECTION.
37 1001121061 1 Hood Assembly - Fixed Tank Side
Ref Note: Replacement Decals must be Purchased Separately -
See DECALS SECTION.
38 1001121118 AR Shim 3mm
