SECTION 7 - ELECTRICAL
226 660SJ/600S 3121299
FIGURE 7-2. HARNESS COMPONENTS INSTALLATION
ITEM PART NUMBER QTY DESCRIPTION REV
Ref USAGE CHART:
Ref USA Built Machines (SN 0300171769 through 0300181891)
Ref China Built Machines (SN B300000869 to Present)
1001107753 Ref PLATFORM BOX HARNESS ASSEMBLY F
19 4460866 1 Terminal, 19 Pin Receptacle
20 4460874 1 Connector - 35 Position (Natural)
21 4460875 1 Connector - 35 Position (Gray)
22 4460873 1 Connector - 35 Position (Black)
23 4460871 79 Socket, Female
24 4460464 7 Pin, Male (16 Gauge)
25 4460879 1 Terminal, Housing 2 Position
26 4460887 2 Terminal, (12 Gauge)
30 4460418 9 Connector - 6 Position
31 4460419 27 Terminal, Female
32 4120035 13 Base, Light
36 4460225 1 Plug, Male- 6 Position
37 4460227 6 Pin, Male
41 4460508 3 Pin, Male (12 Gauge)
43 4460434 2 Connector - 15 Position
44 2920129 13 Lamp, Indicator
47 4460905 26 Plug, Seal
1001145895 Ref PLATFORM BOX ASSEMBLY COMPONENTS B
103 0100048 AR Grease, Dielectric
106 1001117174 1 Footswitch Harness (Includes Footswitch)
106 1060918 7.5
ft/2.3m
Cable, Electrical - 18/3
106A 4460071 1 Connector, Strain Relief
106B 4460226 2 Socket, Female
106B 4460464 1 Pin, Male
113 See Note 1 Controller Harness Assembly (Lift and Swing) (Note: Not Available
for Purchase.)
113A 7022819 1 Plug, Male - 8 Position (Natural)
113A 4460871 8 Socket, Female
114 See Note 1 Controller Harness/Circuit Board Assembly (Drive and Steer)
(Note: Not Available for Purchase.)
114A 7022825 1 Plug, Male - 8 Position (Black)
114A 4460871 7 Socket, Female
131 See Note 1 Controller Harness (Speed Control) (Note: Not Available for
Purchase.)
131A 4460224 1 Receptacle, Female - 6 Position
131A 4460226 6 Socket, Female
136 4460428 2 Connector, Strain Relief
137 4460470 1 Nut, Terminal
138 4460471 1 Lockwasher, Terminal
139 4460708 2 Connector, Female - 15 Position
143 4922666 1 Harness, Analyzer Cable 2-B
143 4460226 4 Socket, Female (Not Shown - Located at J2)
143A 4460761 1 Connector, Female - 4 Position
143A 4460227 4 Pin, Male
145 1001107753 1 Harness, Platform Console Box Options (Includes Items 1-44):
