Page 33
SECTION 1 - FRAME
3121299
660SJ/600S
33
FIGURE 1-8. TOW PACKAGE INSTALLATION (OPTIONAL)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
TOW PACKAGE INSTALLATION
Ref
USA Built Machines:
1001150571
Ref
ANSI Spec
C
1001150570
Ref
CSA Spec
C
1001150569
Ref
CE Spec
A
Ref
China Built Machines:
1001150571
Ref
ANSI Export Spec
C
101
0100011
AR
Compound, Locking
102
0270528
1
Bar Assembly (See Items 201-221 for Breakdown)
103
0641516
2
Bolt 5/16in-18NC x 2in
104
Ref
Decal - Crushing Options:
104
1704578
2
ANSI/CSA Spec
104
1706960
2
CE Spec
105
Ref
Decal - Towing Instructions Options:
105
1705090
1
ANSI Spec
105
1705820
1
CSA Spec
105
Not Required
1
CE Spec
106
Ref
Nameplate - Steer/Tow Select Valve Options:
106A
3250872
1
ANSI Spec
106B
1704272
1
CSA Spec
106C
1706957
1
CE Spec
107
Ref
Screw, Self-Tapping #6-32NF x 1/2in Options:
107
3940604
4
ANSI/CSA Spec
107
Not Required
4
CE Spec
108
4420051
2 ft/.61m
Tape, Safety
109
4640261
1
Valve, Select
0270528
Ref
TOW BAR ASSEMBLY
A
201
0100011
AR
Compound, Locking
202
0362910
1
Pintle, Draw Eye
203
0642010
4
Bolt 5/8in-11NC x 1-1/4in
204
0721004
2
Screw, Hex Machine
205
0741607
24
Screw, Countersunk 3/8in-16NC x 7/8in
206
1060584
6
Cable, Lanyard
207
3420372
2
Pin, Cotter
208
3420447
1
Pin, Towing
209
3421565
2
Pin, Snap
210
3422841
2
Pin
211
3422847
1
Pin
212
3572009
2
Plate, Slide Stop
213
3572010
2
Plate, Slide Stop
214
3572011
2
Plate, Slide Stop
215
3572012
2
Plate, Slide Stop
216
3760170
8
Ring, Split
217
4568133
1
Tube, Tow Bar
218
4740036
1
Flatwasher
219
4751000
2
Flatwasher #10 Regular
220
4846295
1
Tow Bar Attach Weldment
221
4846296
1
Pintle Attach Weldment
