Eppendorf 2350 Biological Shakers Innova - Manual (Page 28)

Technical data
New Brunswick
™ Innova ® 2300/2350 Shakers
English (EN)
28
7.1.2 Innova 2350
Tab. 7-2: Shaking
Contruction • Heavy gauge steel
• Phosphate coated
• Textured painted frame
Weight Net • 49 kg (108 lb)
Gross • 66 kg (145 lb)
Dimensions
Width 74 cm (29 in)
Depth 56.5 cm (22 1/4 in)
Height 17 cm (6 3/8 in)
Platform dimensions
Width 46 cm (18 in)
Depth 76 cm (30 in)
Speed • 25 rpm – 400 rpm • 25 rpm – 300 rpm
Motion • 25.4 mm (1 in) diameter circular orbit • 50.8 mm (2 in) diameter circular
orbit
Indication • LED digital electric display
• 1
rpm increments
Setpoint and
control • Digital adjustment with PI microprocessor control and instantaneous visual
feedback
Accuracy • ±1 rpm
At 25 – 400 rpm, the unit will perform to specifications with up to ±10 % line voltage
fluctuation. To attain speed accuracy at 401 – 500, the line voltage cannot be lower than 5 %
of the rated voltage.
Drive • Eccentric counterbalanced ball bearing drive
Keypad timer • Programmable shaking periods from 0 hr 1 min – 99.9 hr by a digital timer
• Timer shuts off at the end of shaking period and energizes status light
• Timer counts down and digital display indicates remaining time
• Can be deactivated for continuous operation
• Unit will display total accumulated running time for service information
Operating ambient
environment • 0 °C – 60 °C
• 90 %
• Non-condensing
• Up to 2000 m
