3

Eppendorf SmartBlock — Instructions for use

Instructions for use

Eppendorf SmartBlock

see

on p.

Fig.

Tab.

p.

Instructions for use

1

Operating instructions

1 Operating instructions

1.1 Using this manual

These instructions for use are a supplement to the operating manual of the

ThermoMixer C and ThermoStat C devices. These instructions for use do not replace

the operating manual.

Read the operating manual of the corresponding device before using the thermoblock

for the first time. The current version of the operating manual can be found on our

website at

www.eppendorf.com

.

2

Product description

2 Product description

2.1 Features

The thermoblocks (SmartBlocks) for the ThermoMixer C and ThermoStat C devices

enable comfortable tempering and mixing of samples in lab vessels for the microliter

and milliliter range.

* Only in combination with ThermoStat C.

Thermoblock

Tubes/Plates

Maximum

mixing

frequency

Maximum

temperature

SmartBlock 0.5 mL

Tube volume 0.5 mL

2 000 rpm

100 °C

SmartBlock 1.5 mL

Tube volume 1.5 mL

2 000 rpm

100 °C

SmartBlock 2.0 mL

Tube volume 2.0 mL

2 000 rpm

100 °C

SmartBlock 5.0 mL

Tube volume 5.0 mL

1 000 rpm

100 °C

SmartBlock 12 mm

Tubes with a diameter

of 11 mm to 11.9 mm

2 000 rpm

110 °C*

SmartBlock cryo

Cryotubes

2 000 rpm

110 °C*

SmartBlock 15 mL

Conical tubes

volume 15 mL

1 000 rpm

100 °C

SmartBlock 50 mL

Conical tubes

volume 50 mL

1 000 rpm

100 °C

SmartBlock plates

Microplates
Deepwell plates

3 000 rpm
2 000 rpm
1 000 rpm

100 °C

< 80 °C
> 80 °C

SmartBlock PCR 96

96-well PCR plates,

PCR tubes 0.2 mL

2 000 rpm

100 °C

SmartBlock PCR 384

384-well PCR plates

3 000 rpm

100 °C
